Temperature Controllers

Temperature controllers are used to identify measured temperature and release output to maintain desired temperatures.

TN Series 2-DOF PID Temperature Controllers (Program/Fixed Control)

The TN series temperature controllers offer high precision temperature control with two-degree- of-freedom PID algorithm, high-speed sampling speed of 50 ms and ±0.2% measurement accuracy. The temperature controllers feature simultaneous heating and cooling control, group PID, zone PID control and anti-reset windup functions for optimal temperature control in various applications.

• 2-DOF PID algorithm optimized for various control applications
• 50ms high-speed sampling rate and ±0.2% display accuracy
• Program control and fixed control models available

TH4M Series LCD Temperature/Humidity Controllers

The TH4M series temperature/humidity controllers allow simultaneous temperature and humidity control with the included THD-RM temperature/humidity sensor. The controllers display the current temperature/humidity on the front LCD display and output a replay ON/OFF control signal according to user settings.

• Simultaneous temperature and humidity control
• Large LCD display with easy-to-read PV characters
• Temperature and humidity input correction function

TR1D Series Slim Single Display PID Temperature Controllers

The TR1D series slim single display PID temperature controllers feature high-speed sampling cycle rate of 50ms with ±0.3% display-accuracy. The controllers offer high precision temperature control with simultaneous heating and cooling control. The space-saving design with 22.5mm width and DIN rail bracket allows easy installation in limited spaces. The front display can be easily used to set the control status and parameters.

• Compact, space-saving design with 22.5mm width size
• 50ms high-speed sampling and ±0.3% display accuracy
• Simultaneous heating/cooling and automatic/manual control function

TMH Series Modular Multi-Channel High Performance Temperature Controllers

The TMH series modular multi-channel high-performance temperature controllers offer advanced control capabilities. Capable of simultaneously controlling up to 2 or 4 channels of input/output, these controllers provide a high-speed sampling cycle of 50 ms and an impressive measurement accuracy of ±0.3%. Notably, they also feature a unique simultaneous heating and cooling control function. What’s more, expanding the control channels is effortless, requiring no additional wiring for power or communication. With the ability to expand the control modules up to 32 units and 128 channels, users have the flexibility to scale their system according to their specific needs.

Moreover, the TMH series supports seamless connectivity through various communication modules. Each communication module allows for the expansion of up to 32 units, accommodating 16 control modules and 16 option modules. By connecting up to 16 communication modules to a master device, users can achieve an impressive total of 1,024 control channels. This modular design empowers users to customize their setup with ease. Additionally, a range of option modules are available, including analog input/output modules, digital input/alarm output modules, CT input modules, PLC ladder-less communication (RS422/485), and Ethernet communication modules. Parameter configuration and status monitoring can be conveniently performed using PCs with USB, RS422/RS485, or Ethernet communication connections.

• Easy maintenance with detachable body and base terminal
• Power supply and communication with expansion connectors (up to 32 units)
• Parameter configuration with PCs (USB or RS485 communication) : DAQMaster software provided (comprehensive device management software)

TX Series LCD Display PID Temperature Controllers

The TX series temperature controllers feature easy-to-read LCD displays with large, 15.3 mm white PV characters. The 11-segment displays used for PV and SV are useful for displaying various alphanumeric characters and provide improved legibility. The temperature controllers also feature 50 ms high-speed sampling cycle and ±0.3% display accuracy. The space-saving design with 45 mm depth allows easy installation in limited spaces. The TX series also offers various output options including current output, transmission output and RS485 communication output, for application in various environment settings.

• 50 ms high-speed sampling rate and ±0.3% display accuracy
• Large LCD display with easy-to-read white PV characters
• Switch between current output and SSR drive output

TK Series High Performance PID Temperature Controllers

The TK series high performance PID temperature controllers feature high-speed sampling cycle rate of 50 ms with ±0.3% display-accuracy. The controllers offer high precision temperature control with features such as simultaneous heating and cooling control and automatic/manual control options. The all-purpose temperature controllers are available in various sizes and input/output options, for stable and precise temperature control of any required application.

• 50 ms high-speed sampling rate and ±0.3% display accuracy
• Simultaneous heating and cooling control function
• Switch between current output and SSR drive output

TCN Series Economical Dual Display PID Temperature Controllers

The TCN series dual display PID temperature controllers offer excellent performance and cost efficiency. The controllers offer high-speed sampling rate of 100 ms and ±0.5% display accuracy. Relay output and SSR drive output are both supported. The TCN series models can simultaneously display PV and SV. The bright LED displays with large characters provide easy and clear value readings.

• 100 ms high-speed sampling rate and ±0.5% display accuracy
• Switch between relay output and SSR drive output
• Dual digital display (PV/SV)

TC Series Economical Single Display PID Temperature Controllers

The TC series single display PID temperature controllers offer excellent performance and cost efficiency. The controllers feature high-speed sampling rate of 100 ms and ±0.5% display accuracy. Relay output and SSR drive output are both supported. The TC series models can easily switch between PV and SV. The bright LED displays with large characters provide easy and clear value readings.

• 100 ms high-speed sampling rate and ±0.5% display accuracy
• Switch between relay output and SSR drive output
• Single digital display (switch between PV and SV)

TA Series Analog Non-Indicating Type PID Temperature Controllers

The TA series temperature controllers offer simple and accurate temperature control with analog dial. The controllers are capable of auto-tuning PID temperature control and ON/OFF control, toggled through an external switch. The LED deviation and control output indicators provide clear status display.

• Auto-tuning PID temperature control
• PID and ON/OFF control: toggle via external switch
• Deviation indicators (green, red LED) and control output indicator (red LED)

TZ Series Dual-Speed PID Temperature Controllers with Protection Cover

The TZ series temperature controllers are equipped with dual speed PID control for high-speed or high-precision temperature control. The temperature controllers feature ±0.3% high display accuracy, 2-step auto tuning function and supports up to 13 different types of inputs, providing outstanding temperature control at affordable costs.

• Dual-speed PID control
• 2-step auto tuning function
• High display accuracy: ±0.3% of full-scale value

TZN Series Dual-Speed PID Temperature Controllers

The TZN series temperature controllers are equipped with dual speed PID control for high-speed or high-precision temperature control. The temperature controllers feature ±0.3% high display accuracy, 2-step auto tuning function and supports up to 13 different types of inputs, providing outstanding temperature control at affordable costs.

• Dual-speed PID control
• 2-step auto tuning function
• High display accuracy: ±0.3% of full-scale value

TM Series Modular Multi-Channel PID Temperature Controllers

The TM series modular type PID temperature controllers are capable of controlling up to 4 channels (TM4) or 2 channels (TM2) simultaneously. Using the expansion connectors, the TM series can be easily expanded to control up to 124/62 channels (TM4/TM2) without additional wiring for power or communication. The temperature controllers feature high-speed sampling cycles (TM4: 100 ms / TM2: 50 ms), RS485 communication support, and simultaneous heating and cooling control. Parameter configuration and status monitoring via PC is easy with the included DAQMaster software.

• Multi-channel (4-channel: TM4 / 2-channel: TM2) input and output control
• High-speed sampling cycle (4-channel: 100 ms / 2-channel: 50 ms)
• Module connection and expansion with expansion connectors

T3/T4 (Thumbwheel Switch) Series Thumbwheel Switch Digital Temperature Controllers

The T3/T4 Series thumbwheel switch temperature controllers and indicators provide quality performance with simple operation at low costs. The controllers and indicators feature highly accurate temperature measurement and control and are available in various sizes for installation flexibility. Upgraded features include a revamped design and reduced size.

• Various control output options: relay, SSR drive, current
• 2 independent set points and control outputs for heating and cooling control (T4LP)
• Various sizes (W 48 x H 48, W 48 x H 96, W 72 x H 72, W 96 x H 96 mm)

TC3YF Series Refrigeration Temperature Controllers

The TC3YF refrigeration temperature controllers offer reliable and optimal cooling control with diverse features and functions. The controllers offer ON/OFF control using compressor output and optional models with defrost output and evaporator fan outputs are available. Operation cycle programming is also available, to protect contents of the refrigerator in case of errors.

• ON/OFF control
• Standard input type: thermistor (NTC) *RTD (Pt100Ω) input models available upon request.
• Temperature range: – Thermistor (NTC): -40.0 to 99.9 °C (-40 to 212 °F) – RTD (Pt100Ω): -99.9 to 99.9 °C (-148 to 212 °F)

TF3 Series High Performance Refrigeration Temperature Controllers

The TF3 series refrigeration temperature controllers offer reliable and optimal cooling control with diverse features and functions. The controllers are available in standard refrigeration and air-cooling panel installation sizes for convenient installation. The series also features various user-friendly functions including defrost sync function, real-time clock function, alarm function, night-mode, communication output and more. Users can also remotely monitor real-time temperature and output status with the remote display units (TFD series, sold separately).

• Standard installation size for refrigeration panels (W 70.3 x H 28.2 mm)
• Various compressor load current capacity: 5A, 16A, 20A
• Various user-friendly functions (defrost sync, real-time clock, alarm, etc.)

T3/T4 (Indicator) Series Digital Temperature Indicators

The T3/T4 series digital temperature indicators provide accurate temperature display with simple operation. The indicators feature highly accurate temperature measurement and are available in various sizes for installation flexibility. Upgraded features include a revamped design and reduced size.

• Digital Temperature Indicators
• Additional input sensor types: K(CA) and J(IC) (T3NI models)
• Various sizes (W 48 x H 24, W 48 x H 48, W 48 x H 96, W 72 x H 36, W 72 x H 72, W 96 x H 48, W 96 x H 96 mm)

KPN Series Bar Graph Temperature Controllers

The KPN series high performance digital process controllers offer high-speed sampling speed of 50 ms and high display accuracy of ±0.3%. The large, high luminance LED dual display provides clear PV and SV readings with bar graph display of control output value (MV). The series also feature high performance control with independent heating/cooling control and automatic/manual control functions.

• High speed sampling of 50ms and ±0.3% display accuracy
• Enable to check control output operation amount by adopting bar graph
• Simultaneous heating/cooling control and automatic/manual control for high performance control

Timers

Analog and digital timers are widely used in various industrial processes to control timing of devices or monitor life cycles of devices.

LE7M-2 Series Digital Week/Year Timers

The LE7M series digital week/year timers allow time configuration and control in week or year units. Simple configuration and status monitoring is possible with 2 independent built-in relay control outputs. DIN rail mount type is available for convenient installation. (size: DIN W72XH72 mm)

• Various external input functions
• Backlight display with high visibility
• Simple configuration and status monitoring

LE8N Series Compact 8-Digit LCD Digital Timers (Indicator Only)

The LE8N series LCD timers feature an 8-digit display with backlight (backlight models). The compact size allows easy installation in tight spaces and the built-in lithium battery allows the units to operate without external power supplies. Various time setting ranges are supported and no-voltage input, voltage input, and AC/DC universal voltage models are available.

• Compact size: DIN W 48 x H 24 x L 54 mm
• Built-in lithium battery (operates without external power supply)
• Input signal types: no-voltage input, voltage input, AC/DC universal voltage input

LE3S Series Thumbwheel Switch LCD Display Digital Timers

The LE3S series digital timers feature simple and easy control with thumbwheel switches in the front and up/down mode selection switch in the rear. 10 output operation modes and 10 time setting ranges are available for various timing applications. Users can quickly identify operation status with output type display and time progress bar graph.

• Compact, space-saving design (W 48 x H 48 x L 67 mm)
• Simple configuration with thumbwheel switches
• 10 output operation modes (LE3S)

LE4S Series LCD Display Digital Timers

The LE4S series digital timers feature LCD Backlight display with compact, space-saving design. The timers also feature various output operation modes as well as configurable time setting range and one-shot output time for diverse applications. Users can configure set value and time range independently in flicker, flicker I, ON-OFF delay, and ON-OFF delay I modes.

• Compact, space-saving design (W 48 × H 48 × L 70 mm)
• Configure set value and time range independently (Flicker, flicker I, ON-OFF delay, ON-OFF delay I modes)
• LCD backlight with ON/OFF function

FSE Series 8-Pin Plug Type Digital Timers

The FSE series digital timers feature a wide time setting range between 0.01 seconds to 9999.9 hours. Simple configuration is possible with the front thumbwheel switches. The 8-pin plug type connection allows easy installation and maintenance. The FSE series timers are available in 4-digit and 5-digit models.

• Wide time setting range: 0.01 s to 9999.9 h
• Switch between voltage input (PNP) and no-voltage input (PNP) using DIP switch
• Set hr/min/sec display with RESET key

ATM Series Miniature Analog Timers

The ATM series miniature analog timers feature compact, space-saving design (W 21.5 x H 28 mm) with a simple 14-pin plug-in socket. The ATM series is available in 11 different time ranges (0.1 sec to 3 hr) and various power supply options. The timers feature 4PDT contacts, quick reset time of 100 ms, and repeat accuracy of ±0.5% for highly accurate timing control.

• Ultra-compact, miniature size (W 21.5 x H 28 x L 59.3 mm)
• 4PDT contacts (250 VAC, 3 A)
• Highly accurate timing control with analog dial

ATS Series Compact Multi-Function Analog Timers

The ATS series compact multi-function analog timers feature 6 output operation modes and 12 time setting ranges for application in diverse timing control tasks. The timers also feature a wide time setting range between 0.1 seconds to 30 hours depending on the model. Simple time configuration and operation is possible with the analog dial control. The ATS series is available in 8-pin or 11-pin plug models.

• 6 output operation modes
• 12 time setting ranges
• Wide time setting range: 0.1 s to 30 h

ATS8SD-4 Series Compact Star-Delta Analog Timers

The ATS8SD-4 star-delta analog timers are ideal for starting high capacity motors with star-delta transition. Various time setting ranges and star-delta switching time can be configured easily with adjustment switches. Standard DIN W 48 x H 48 mm brackets are included for convenient installation.

• Ideal for starting high capacity motors
• Various time setting range and star-delta switching time
• Standard DIN W 48 x H 48 mm bracket included

ATS8P Series Compact Power OFF Delay Analog Timers

The ATS8P series power-off delay analog timers are ideal for circuit protection and system restart in case of power failures. Simple time configuration and status monitoring is possible with the analog dial. Time range can be set in seconds or minutes depending on the model type. Standard DIN W 48 x H 48 mm bracket is included for convenient installation.

• Ideal for circuit protection and system restart in case of power failures
• Simple time configuration and status monitoring with analog dial
• Standard DIN W 48 x H 48 mm bracket included

ATS8W/ATS11W Series Compact Analog Twin Timers

The ATS8W/11W series analog twin timers feature 6 output operation modes and 12 time setting ranges for application in diverse timing control tasks. The timers feature independent dials for separate ON/OFF timing control. Simple time configuration and operation is possible with dual analog dials. The ATS8W models support 8-pin connection and the ATS11W models support 11-pin connection.

• Independent ON/OFF time control
• 6 output operation modes
• 12 time setting ranges

ATN Series Multi-Function Analog Timers

The ATN series multi-function analog timers feature 6 output operation modes and 12 time setting ranges for application in diverse timing control tasks. The timers also feature a wide time setting range between 0.05 seconds to 100 hours. Simple time configuration and operation is possible with the analog dial control. The ATN series is available in 8-pin or 11-pin plug models.

• Simple time setting, time range, and output operation configuration with analog dial and switches
• 6 output operations
• 16 time setting ranges

AT8SDN Series Star-Delta Analog Timers

The AT8SDN star-delta analog timers are ideal for starting high capacity motors with star-delta transition. Various time setting ranges and star-delta switching time can be configured easily with adjustment switches. LED start/delta operation indicators allow users to easily identify the operation status of the timers.

• Ideal for starting high capacity motors
• Various time setting range and star-delta switching time
• Simple time setting, time range, and output operation configuration with analog dial and switches

AT8PSN/AT8PMN Series Power OFF Delay Analog Timers

The AT8PSN/AT8PMN series power-off delay analog timers are ideal for circuit protection and system restart in case of power failures. Simple time configuration and status monitoring is possible with the analog dial. Time range can be set in seconds or minutes depending on the model type. Standard DIN W 48 x H 48 mm size provides convenient installation.

• Time setting range: (AT8PSN: 0.05 to 10 seconds / AT8PMN: 0.05 to 10 minutes)
• Simple time configuration and status monitoring with analog dial
• Ideal for circuit protection and system restart in case of power failures

ATE8 Series Simple Operation Analog Timers

The ATE8 series timers offer simple configuration and operation with analog dial. Various time ranges and output options are available by model. Standard DIN W 48 x H 48 mm size provides convenient installation.

• Simple configuration and operation with analog dial
• Various time setting ranges
• Standard DIN W 48 x H 48 mm size

Recorders

Recorders are devices which display and record various measured inputs including temperature, humidity, flux, and pressure.

KRN50 Series 50 mm Compact Hybrid Recorders

The KRN50 series 50 mm hybrid recorders are compact-sized recorders including main functions of larger sized recorders. The data logger function allows paperless recording and data backup.

• 50mm thermal transfer method of paper recorder
• Data logger function for recording without paper
• 2-channel simultaneous recording – graphic mode, digital mode

KRN100 Series 100 mm Hybrid Recorders

The KRN100 series hybrid recorders can measure and record various industrial data including temperature, level, pressure and more. The measured values can be displayed on the LCD screen or printed on strip charts. Measurement data can be stored on the USB memory and can be printed later using the data logger function. Remote parameter setting is possible through USB connection. The recorders support up to 12 input channels with slot type input cards.

• 100mm paper recorder
• Writable data logger function without paper (supports internal memory and external USB memory data backup)
• 25 to 250ms high speed sampling, 10 to 240mm/H high graph mode recording

KRN1000 Series LCD Touchscreen Paperless Recorders

The KRN1000 series paperless recorders feature 5.6-inch TFT color LCD (640×480) touchscreen displays with excellent visibility and intuitive control interface. The recorders can process 27 types of input with high-speed sampling rate up to 25 ms and recording cycle between 1 to 3600 s. Various communication methods are supported along with high capacity storage memory (internal/external). Users can also cycle between 9 different graph types, depending on the required application. The series is available in 4, 8, 12, 16 input channel models with various input/output options.

• 5.6-inch TFT color LCD (640×480) touchscreen display with excellent visibility and intuitive control interface
• Supports 27 input types (thermocouple, RTD, analog voltage and current[shunt])
• 25 to 250 ms high-speed sampling, 1 to 3600 s recording cycle

Sensor Controllers

Sensors controllers are used to apply various forms of logic and functions to input signals from sensors and transmit relay or transistor signals.

PA10 Series High Performance Sensor Controllers

The PA10 series sensor controllers offer high performance control with various operation modes. The PA10 series features high-speed output response and convenient installation with both DIN rail and panel mount options. The PA10 series is available in general-purpose type, 2-channel type, and high performance type models.

• High-speed output response
• 13 operation modes using DIP switch (PA10-U)
• Flip-flop mode for level control (PA10-U)

PA-12 Series 8-Pin Plug Type Sensor Controllers

The PA-12 series sensor controllers feature 8-pin plugs for simple socket plug-in type connection. The sensor controllers offer dual 110/220 VAC voltage, for application in diverse settings. The series also offers high contact capacity and options for N.O. or N.C. relay outputs. Users can easily switch between NPN and PNP inputs using the attached conversion switch.

• 110/220 VAC dual voltage
• NPN/PNP input switch
• High contact capacity (250 VAC, 3A resistive load)

Digital Display Units

Digital display units are available in various sizes, can display over 60 different characters and signals for various monitoring purposes.

D1AA Series Small 16-Segment Digital Display Units

The D1AA series 16-segment digital display units are small, compact size (W 11 x H 22 mm) LED displays capable of displaying 61 unique characters (0 to 9, A to Z, 24 symbols, period). Input logic can be alternated between positive (PNP) and negative (NPN) by simple soldering. The displays accept both parallel and serial data input. Multi-stage connection is possible with multiple units and the displays are available in red and green display models.

• Display 61 unique characters (0 to 9, A to Z, 24 symbols, period)
• Input logic: positive (PNP), negative (NPN)
• Data input method: parallel, serial

D1SC-N Series Large 7-Segment Digital Display Units

The D1SC-N 7-segment digital display units are large (W 32 x H 57 mm) LED displays with options for decimal (0 to 9) and hexadecimal (0 to 9, A to F) characters. Input logic can be alternated between positive (PNP) and negative (NPN) using a simple jumper switch. The displays accept both parallel and serial data input and are highly compatible with various PCs, PLCs, and other control devices.

• Display characters: decimal (0 to 9), hexadecimal (0 to 9, A to F)
• Input logic: positive (PNP), negative (NPN)
• Data input method: parallel, serial

D1SA Series Small 7-Segment Digital Display Units

The D1SA series 7-segment digital display units are small, compact size (W 11 x H 22 mm) LED displays with options for decimal (0 to 9) and hexadecimal (0 to 9, A to F) characters. Input logic can be alternated between positive (PNP) and negative (NPN) by simple soldering. The displays accept both parallel and serial data input. Multi-stage connection is possible with multiple units and the displays are available in red and green display models.

• Display characters: decimal (0 to 9), hexadecimal (0 to 9, A to F)
• Input logic: positive (PNP), negative (NPN)
• Data input method: parallel, serial

D5Y/D5W Series Panel Mount 5-Digit Digital Display Units

The D5Y/D5W series digital display units are panel mount type units with 5-digit, 7-segment LED displays. Various parallel and serial data input methods are supported. Users can conveniently switch data input methods, display digit, input logic, symbol display function, and zero blanking function with attached DIP switches. The D5Y models are W 72 x H 36 mm and the D5W models are W 96 x H 48 mm in size.

• Various data input methods: static parallel input, dynamic parallel input, 4/5-bit serial input, 16/20/25-bit serial input
• Decimal point and minus sign display function
• Input logic: positive (PNP), negative (NPN)

DS/DA Series Intelligent Type Digital Display Units

The DS/DA series Intelligent type display units are available in 6 input options, including serial input, parallel input, RS485 communication input, RS485 communication time sync display, PT temperature sensor input, and PT temperature sensor + RS485 communication input. The DS/DA series is expandable up to 24 units with simple multi-stage connection, and switchable unit plates are available to provide installation flexibility for users. The displays are available in 7-segment, 16-segment types and green, red LED types and diverse combinations are possible.

• Simple wiring without soldering
• Various input options (6 types)
• Expandable up to 24 units with multi-stage connection
