Sensors
Sensors are commonly used components in automation used to detect changes in the environment and transmit the information electronically.
Product Lineup
Photoelectric Sensors
Photoelectric sensors are used to detect distance, absence or presence of objects using a light transmitter and receiver.
BRQ Series Cylindrical Photoelectric Sensors
The BRQ series Ø18 mm cylindrical photoelectric sensors are available in various sensing sides (front, side), housing material (SUS316L stainless steel, nickel-plated brass metal, plastic), and body sizes (standard, short-body) for flexible application in diverse environments. The sensors feature long detection distance up to 30 m and accurate sensing performance with excellent noise immunity and minimal influence from ambient light. Mutual interference prevention function also allows the sensors to be installed close together. With IP67 protection rating, the sensors offer stable and error-free operation even in wet or dusty environments. The IP67K models are also available for application in high pressure and high temperature water and dust environments.
- Ø18 mm head cylindrical photoelectric sensors
- Various body housing material: stainless steel, metal, plastic
- Various body sizes: standard, short body
- Front sensing type, side sensing type available
BJX Series Compact Long Distance Photoelectric Sensors
The BJX series compact photoelectric sensors feature high performance lens with long sensing distance up to 30 m. The sensors also offer excellent noise immunity and minimal influence from ambient light for accurate and reliable presence detection. Mutual interference prevention function allows tight adjacent installation of multiple sensors and MSR (mirror surface rejection) function allows detection of highly reflective targets.
- • High performance lens with long sensing distance
- – Through-beam type: 30 m, Diffuse reflective type: 1 m, Retroreflective type: 3 m (MS-2A)
- Compact size: W 20 x H 32 x L 11 mm
- M.S.R (Mirror Surface Rejection) function (retroreflective type)
- Light ON/Dark ON operation mode switch
BC Series Color Mark Sensors
The BC series color mark sensors offer outstanding color matching accuracy for highly reliable and stable color detection. The sensors generate RGB light emitting diodes with 12-bit resolution processing for high color matching accuracy and offer 2 different detection modes with 3-step sensitivity adjustment. The W 1.24 x L 6.7 mm spot size allows the sensors to detect tiny targets and color marks. With an IP67 protection structure, the sensors can provide stable and error-free operation even in wet or dusty environments.
- Outstanding color matching accuracy: RGB light emitting diodes and 12-bit resolution, 2 detection modes (color only/color+intensity), 3-step sensitivity adjustment for each mode (fine, normal, rough)
- Check reference color with teaching indicator
- Operation indicator (red LED), stability indicator (green LED), timer indicator (orange LED)
- W 1.24 x L 6.7 mm spot size for detection of tiny targets and color marks
- IP67 protection structure (IEC standard)
BH Series Front/Side Mount Photoelectric Sensors
The BH series photoelectric sensors are capable of front mounting using M18 nut and fastening cap or side mounting using M3 bolt screw and nuts. The flexible installation options allow easy application in various industrial settings. The sensors can produce individual or simultaneous NPN and PNP open collector outputs by simple wire configuration. The IP67 protection structure provides stable and error-free operation even in wet or dusty environments.
- Front mounting (M18 nut) or side mounting (M3 screws)
- Simultaneous NPN/PNP open collector output
- Sensing distance – Through-beam type: 20 m, Retroreflective type: 4 m, Diffuse reflective type: 1 m, 300 mm
- Compact size: W 14 mm x H 34.5 mm x L 28 mm
- Mirror Surface Rejection (MSR) function allows stable detection of highly reflective targets (retroreflective type only)
BL Series Photoelectric Liquid Level Sensors
The BL series photoelectric liquid level sensors can detect the presence or absence of liquid in transparent pipes measuring 6 to 13 mm in diameter and less than 1 mm thick. Users can easily select between Light ON and Dark ON operation using the operation mode switch. With a compact design and easy installation, the BL series sensors are ideal solutions for non-contact detection of liquid in transparent pipes.
- Photoelectric sensors for non-contact detection of liquid in transparent pipes
- Detects presence of liquid in transparent pipes (external diameter 6 to 13 mm, <1 mm thick)
- Compact size: W 23 x H 14 x L 13 mm
- Light ON/Dark ON operation mode switch
BEN Series Universal AC/DC Photoelectric Sensors
The BEN series photoelectric sensors with built-in amplifiers are available in universal AC/DC types and DC types. Light ON/Dark ON operation mode switch and sensitivity adjusters are available for easy configuration and set up (except through-beam types). The specialized sensor IC provides high performance in various user applications.
- Universal AC/DC models (relay contact output) available
- Light ON/Dark ON operation mode switch
- Sensitivity adjuster (except through-beam types)
- Stability indicator (green LED) and operation indicator (red LED)
- Specialized, high-performance sensor IC
BUP Series U-Shaped Photoelectric Sensors
The U-shaped photoelectric sensors BUP series are available in 30 mm, 50 mm sensing distance models and sensitivity adjustable models to expand the flexibility for various applications.
- High noise immunity to ambient light
- High-speed response time under 1ms
- Built-in reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit
- Switch between Light ON and Dark ON modes using control wire
BTS Series Ultra-Compact, Slim Photoelectric Sensors
The BTS series ultra-compact, slim type photoelectric sensors are ideal for installation in limited spaces and compact applications. The sensors measure just 7.2 mm wide, come equipped with built-in amplifiers and are capable of detecting tiny objects including metallic wires and semiconductor chips. The BTS Series is also built with IP67 protection structure and stainless steel mounting brackets, providing durable and reliable sensing solutions in diverse environments.
- Ultra-slim width of only 7.2 mm
- Maximum detection distance: 1 m (through-beam type)
- Stability indicator (green LED) and operation indicator(red LED)
- Stainless steel 304 mounting brackets
- IP67 protection structure (IEC standard)
BTF Series Ultra-Compact, Thin Type Photoelectric Sensors
The BTF series ultra-compact, thin type photoelectric sensors are ideal for installation in limited spaces and compact applications. The sensors measure just 3.7 mm in thickness, come equipped with built-in amplifiers and are capable of detecting tiny objects including metallic wires and semiconductor chips. The BTF series is also built with IP67 protection structure and stainless steel mounting brackets, providing durable and reliable sensing solutions in diverse environments.
- Ultra-thin size of only 3.7 mm
- Maximum detection distance : 1 m (through-beam type)
- Stability indicator (green LED) and operation indicator(red LED)
- Stainless steel 304 mounting brackets
- IP67 protection structure (IEC standard)
BPS Series Compact Flat Type
The BPS series compact photoelectric sensors are easy to install with a compact, thin and flat design. The through-beam type sensors have long sensing distances of up to 3 m and protection rating of IP67.
- Compact, thin and flat design for easy installation
- Long sensing distance up to 3 m
- IP67 protection structure (IEC standard)
BJR Series Oil-Resistant Type
The BJR series oil-resistant/oil-proof photoelectric sensors are optimized for use in various environments with cutting oil and lubricants such as automotive and machine tool industries. The sensors are capable of long distance detection up to 15 m (through-beam type). Various features including MSR (Mirror Surface Rejection) function and mutual interference prevention functions allow stable and error-free operation. The screw mounting hole is made of metallic nuts, allowing easy installation using M3 bolts and offering easy maintenance even when exposed to various oils.
- MSR (Mirror Surface Rejection) function (retroreflective type)
- Compact size: W 20 x H 32 x L 11 mm
- Light ON/Dark ON operation mode switch
BA Series Diffuse Reflective Type
The BA series diffuse reflective photoelectric sensors feature specially designed optics with long sensing distance up to 2 m. The sensors are available in Light ON and Dark ON modes and come equipped with built-in sensitivity adjusters. Operation/stability indicator allows users to easily identify operation status.
- Specially designed optics with long sensing distance up to 2 m
- Sensitivity adjuster
- Stability indicator (Light ON: orange, Dark ON: green)
BX Series Universal AC/DC Type
The BX series photoelectric sensors with built-in amplifiers are available in universal AC/DC types and DC types. The terminal type sensors also feature timer function to change between ON delay, OFF delay, and One-shot delay. Light ON/Dark ON operation mode switch and sensitivity adjusters are also available for easy configuration and set up. The universal AC/DC types feature a wide power supply range of 24-240 VAC / 24-240 VDC.
- Sensitivity adjuster available on all models
- Timer function (built-in timer models) : ON delay, OFF delay, One-shot delay
- Output types : relay contact (AC/DC type), NPN/PNP open collector (DC type)
BYD Series Compact Type
The BYD series compact photoelectric sensors with built-in amplifiers offer high performance and value. The compact size and various detection methods make it ideal for various user applications. The sensors are available in through-beam, diffuse reflective, and convergent reflective types. Additionally, BYD30-DDT-U and BYD50-DDT-U models have operation indicators located on the top side for users to better identify operation status.
- Compact size : W 12 × H 32 × L 18 mm
- Performance unaffected by color of the target object (convergent reflective type)
- Operation indicator (red LED) (BYD30-DDT-U, BYD50-DDT-U models : indicator located on the top side)
BJP Series Photoelectric Sensors for PCB Detection
The BJP series photoelectric sensors are optimized for detection of printed circuit boards (PCB) with a 30 mm x 3 mm rectangular light beam and background suppression (BGS) sensing method. The sensors provide accurate and stable detection of PCBs regardless of holes, protrusions or intrusions on the boards. Configuration is made simple with operation mode switch and adjustable sensing distances.
- 30 mm x 3 mm light beam (at 30 mm distance) provides accurate detection of PCBs regardless of holes, protrusions, intrusions, or errors on the boards.
- Background suppression (BGS) sensing method allows stable detection regardless of the color, texture or surface of the background object.
- Sensing distance: 10 to 100 mm (adjustable distance: 20 to 100 mm)
BJ Series Compact High Performance Photoelectric Sensors
The BJ series compact photoelectric sensors feature high performance and excellent noise immunity for accurate and reliable presence detection. Light ON/Dark ON operation mode switch and sensitivity adjusters are available for easy configuration and set up (except BJG-DDT). The sensors are available in various types and options, making it ideal for diverse applications. The BJ series is available in long distance type, BGS (background suppression) reflective type, transparent glass sensing type, and micro spot types, and the sensors are available in cable types and connector types (long distance type models).
- Compact size : W 10.6 × H 32 × L 20 mm
- IP65 protection structure (IEC standard) / IP67 for BJ-C connector types
- Light ON/Dark ON operation mode switch (except BJG30-DDT)
BY Series Compact Photoelectric Sensors with Synchronous Detection
The BY series compact through-beam type photoelectric sensors offer highly reliable sensing performance with a synchronized emitter and receiver system and high-speed response time under 1 ms. The sensors are available in standard types and side sensing types for installation flexibility.
- Compact size : W 12 × H 30 × L 16 mm
- Synchronous detection between emitter/receiver reduces errors from ambient light
- Built-in reverse polarity protection circuit and output overcurrent(short-circuit) protection circuit
BM Series Economical General-Purpose Photoelectric Sensors
The BM series photoelectric sensors are easy to install and use in various industrial applications. The sensors feature built-in reverse polarity protection circuits and diffuse reflective type models feature built-in sensitivity adjusters. The BM series is available in through-beam type, retroreflective type, and diffuse reflective types.
- Compact and light for easy installation
- Sensitivity adjuster (diffuse reflective type)
- Easy bolt/screw installation
BMS Series Side Sensing Type Photoelectric Sensors
The BMS series side sensing type photoelectric sensors feature high-speed response time under 1 ms. Users can also switch between Light ON and Dark ON modes using the control wire and sensitivity adjuster is included for easier configuration. The sensors are available in through-beam type, retroreflective type, and diffuse reflective types.
- Built-in reverse polarity protection circuit and output overcurrent (short-circuit) protection circuit
- High-speed response time under 1 ms
- Switch between Light ON and Dark ON modes using control wire
BR(NARROW BEAM REFLECTIVE) Series Cylindrical Photoelectric Sensors (Narrow Beam Reflective Type)
The BR series Ø18 mm cylindrical photoelectric sensors feature high-speed response time under 1 ms and excellent noise immunity with digital signal processing. The sensors are ideal for installation in limited spaces, with narrow-beam reflective type sensing. Connector type sensors are also available, offering easier maintenance and wiring work.
- Excellent noise immunity with digital signal processing
- High-speed response time under 1 ms
- Sensitivity adjuster
BUM Series 4-Channel U-Shaped Photoelectric Sensors
The BUM series U-shaped photoelectric sensors feature 4 independent outputs and high speed response time under 1 ms for highly reliable and stable presence detection. Each output channel can be controlled individually, and the sensors can be used as an alternative to multiple sensor configurations. The BUM series is specially configured for optimal performance in detection of moving parts including elevator systems.
- Built-in reverse polarity protection circuit and output overcurrent (short-circuit) protection circuit
- Independent 4-channel output
- High-speed response time under 1 ms
Photomicro Sensors
Photomicro sensors are compact sized photoelectric sensors with built-in amplifiers used to detect presence of mechanical parts in equipments.
BS4 Series Groove-Depth 9 mm Photomicro Sensors with Built-In Connector
The BS4 series photomicro sensors are available in 7 different shapes (K, L, R, T, TA, F, Y types) and built-in connector type, offering maximum flexibility for various user applications and installation settings. The sensors are designed to minimize errors occurring from foreign substances. The sensors offer high visibility with operation indicators viewable from multiple directions.
- Compact size with built-in connector
- Dedicated connector cables (sold separately) and universal connector cables supported
- Various shapes available for installation flexibility (K, L, R, T, TA, F, Y types)
BS3 Series Groove-Depth 6.5mm Photomicro Sensors
The BS3 series ultra-compact photomicro sensors are available in 5 different shapes (K, F, R, U, L types), offering maximum flexibility for various user applications and installation settings. The sensors are designed to minimize errors occurring from foreign substances.
- The sensors offer high visibility with operation indicators viewable from multiple directions.
- Ultra-compact size
- Various shapes available for installation flexibility (K, F, R, U, L types)
- Minimize detection errors and improved visibility
BS5 Series Groove-Depth 9mm Photomicro Sensors
The BS5 series photomicro sensors are available in 8 different shapes (K, T, V, L, Y, F, R, TA types), offering maximum flexibility for various user applications and installation settings. The sensors are designed to minimize errors occurring from foreign substances. The sensors offer high visibility with operation indicators viewable from multiple directions.
- Various shapes available for installation flexibility (K, T, V, L, Y, F, R, TA types)
- Minimize detection errors and improved visibility
- Indicator ON when light received and indicator ON when light blocked models available
BS5-P Series Push Button Type Photomicro Sensors
The BS5-P series push button type photomicro sensors are capable of accurate detection regardless of material, color, or reflectivity of target objects. Optical detection by button operation guarantees high mechanical life cycle up to 5 million operations.
- Button switch operation ensures accurate detection regardless of material, color, or reflectivity of target object
- Optical detection (emitter/receiver) by button operation guarantees mechanical life cycle of 5 million operations
- Total of 4 red LED operation indicators on 3 sides (side : 2, top : 2) for higher visibility of operation status
Fiber Optic Sensors
Fiber optic sensors combine optic fiber cables and amplifiers to provide accurate detection of objects in various applications.
BF5 Series High Performance Single/Dual Digital Display Fiber Optic Amplifiers
The BF5 series fiber optic amplifiers are available in single and dual display models. The units feature 5 different response speed settings, for flexible and reliable detection of fast moving targets or small objects. With integrated mutual interference prevention, reliable detection is possible with multiple units (up to 8 units) with connection using side connectors. Other features include saturation prevention function, inverted display, and simple sensitivity adjustment settings. Red, green, and blue LED light source models are available for diverse applications.
- Dual digital display for displaying current value and set value (BF5□-D)
- 5 response speeds : Ultra-fast mode (50 ㎲), fast mode (150 ㎲), standard mode (500 ㎲), long-distance mode (4 ms), ultra-long-distance mode (10 ms)
- Mutual interference prevention allows adjacent installation (up to 8 units) with side connectors
BFX Series LCD Display Digit
The BFX series fiber optic amplifiers feature dual digital LCD display for displaying present value and set value. The amplifier units feature quick response rates up to 50 ㎲, allowing detection of fast moving targets and high accuracy. The units feature 5 different response speed settings and 4 different sensitivity settings, for flexible application in diverse environment settings.
- LCD dual display for displaying present value and
- High resolution (1/10,000) for detecting tiny targets
- Ultra-fast response speed (50 ㎲) for detecting fast moving targets
Fiber Optic Units
The FT/GT, FD/GD, FL/GL series fiber optic units are available in various sensing methods (through-beam, retroreflective, convergent reflective), 9 head types (thread, cylindrical, flat, L-shaped, plastic, perpendicular, stainless steel, U-shaped, area detection), 5 cable types (standard, flexible, break-resistant, heat-resistant, vacuum-resistant) for flexible installation in diverse environments.
- Various head types and sensing methods for diverse environments
- Thread, cylindrical, flat, L-shaped, plastic, perpendicular, stainless steel, U-shaped and area detection head types for various user requirements
- Through-beam, retroreflective and convergent reflective methods are available for diverse working conditions
BFC Series Digital Fiber Optic Amplifier Communication Converters
The BFC fiber optic amplifier communication converters allow simple management and configuration of BF5 series fiber optic amplifiers via PCs or PLCs. The units support RS485 communication and serial communication, as well as switch input. Up to 32 amplifier units may be connected to the BFC converters.
- Allows management and configuration of BF5 series amplifiers via PCs or PLCs
- Various communication methods : RS485 communication, serial communication, switch input
- Supports multiple connection of up to 32 amplifier units (BF5 series)
BF4 Series Digital Display Fiber Optic Amplifiers
The BF4 series fiber optic amplifiers feature high-speed response times and various functions to provide reliable detection of small or fast moving targets. The units feature convenience functions such as auto-sensitivity adjustment and advanced features including mutual interference prevention and self-diagnosis function. The amplifiers can be used together with fiber optic cables from Autonics for optimal performance.
- High-speed response under 0.5 ms
- Auto sensitivity adjustment / remote sensitivity adjustment
- Mutual interference prevention function, self-diagnosis function
BF3 Series Dual Adjustment Fiber Optic Amplifiers
The BF3 series fiber optic amplifiers come equipped with dual adjusters (COARSE, FINE) for precise sensitivity adjustment. The units feature high-speed response time under 1 ms, and users can conveniently switch between Light ON and Dark ON modes using control wires. The amplifiers can be easily mounted on DIN rails and is compatible with various fiber optic cables from Autonics.
- Simple DIN rail mount installation
- High-speed response under 1 ms
- Precise sensitivity adjustment with dual adjusters (COARSE, FINE)
Displacement Sensors
Displacement sensors can measure thickness, width, level difference, disparity, curve, evenness of target objects by detecting the amount of displacement using laser beams.
BD Series Laser Displacement Sensors (Sensor Head and Amplifier Unit)
The BD series laser displacement sensors can measure thickness, width, level difference, disparity, curve, evenness of target objects by detecting the amount of displacement. The sensors offer accurate and stable measurement with minimal influence from target color or material. The sensor head and amplifier unit are detachable for easier maintenance and up to 8 sensor amplifier units can be interconnected with mutual interference prevention function.
- Easy maintenance with detachable sensor head/amplifier unit
- Maximum resolution: 1㎛ (vary by model)
- Accurate measurement with minimal influence from target color or material
BD-C Series Communication Converter for Laser Displacement Sensors
The BD-C series communication converters allow RS232C/RS485 communication for BD series laser displacement sensors. The communication converters can be powered by the sensor amplifier unit by connecting the units using the side connector. The atDisplacement laser displacement sensor software allows users to batch parameter settings, monitor measured values and outputs in real-time, and set communication speed and addresses without connecting to host devices.
- Supports both RS232C and RS485 communication in one device : Separate ports for RS232C and RS485
- Connect up to 8 amplifier units
- Can be powered directly by amplifier units without additional wiring
LiDAR
Laser scanners utilize time-of-flight (ToF) method to measure the round trip time of the infrared laser beam, to accurately detect presence of objects within a wide range area.
LSE Series 2D Laser Scanners
The LiDAR sensors LSE series feature 5.6 m x 5.6 m detection area (90˚) to accurately detect object presence. The scanners offer 4 separate laser beam channels which can be activated individually or simultaneously depending on detection requirements. The units can also set concentrated monitoring areas and non-detection areas for flexible application in diverse environments. The Ethernet communication allows easy configuration with PCs. Users can also configure and manage the units using the provided infrared remote control.
- Detection area : 90˚, 5.6 m x 5.6 m
- Supports up to 4 operation channels
- Compact size (W125 x H80.3 x L88 mm) for diverse applications
LSE2 Series 2D 4-Channel Laser Scanners (for LSE Series)
The LSE2 series LIDAR sensors feature 5.6 m x 5.6 m detection area (90˚) to accurately detect object presence. The scanners offer flexible installation in limited spaces with compact size (W120 x H47.5 x L89.4 mm). The Ethernet communication allows easy configuration with PCs. Users can also configure and manage the scanners with mobile devices using the dedicated atLIDAR application, removing the need for separate remote controls.
- 90° detection angle, 5.6 × 5.6 m detection range
- Compact size for flexible installation (W120 x H46.5 x L89.4 mm)
- Various filter function to prevent malfunction due to fog, rain, snow and dusts
LSC Series 2D 270° Laser Scanners
The LiDAR sensors LSC series feature 270° detection angle and up to 25 m detection distance to accurately detect object presence. The scanners offer 16 field sets and teaching function for flexible installation and Ethernet / Bluetooth communication allows easy configuration with PC and mobile application. The ROS (Robot Operation System) driver is also supported for SLAM (Simultaneous Localization and Mapping) function of AGV/AMR.
- Wide range detection area : 270° detection angle, 25 m detection distance
- Number of field sets : 16 (1 set : consists of 3 subfields)
- Various filter function for accurate detection
Door Sensors
Door sensors are special-purpose photoelectric sensors generally used in automatic door management systems.
ADS-A Series Automatic Door Sensors
The ADS-A series automatic door sensors combine reliable sensing performance with sleek and simple design. The door sensors also feature various functions and features including adjustable hold time switch, 4-step detection angle adjustment, and adjustable detection area functions. With a built-in microprocessor, the ADS-A series door sensors provide optimal processing performance for stable performance in various environments.
- Adjustable hold time switch (2, 7, 15 seconds)
- 4-step detection angle adjustment (7.5˚, 14.5˚, 21.5˚, 28.5˚)
- Power supply : 24-240 VAC / 24-240 VDC (universal AC/DC type), 12-24 VAC / 12-24 VDC (universal AC/DC type)
ADS-SE1/2 Series Automatic Door Side Sensors
The ADS-SE1/2 series automatic door side sensors are through-beam type sensor system with a dedicated controller. The sensors feature long sensing distances up to 10 m and provides stable detection even in high ambient lighting, up to 100,000 lux. Connection between sensor and controller is made easy with push-to-connect wiring and one-touch automatic sensitivity adjustment function is included for convenient set up.
- Long sensing distance : 0 to 10 m
- Ambient lighting : up to 100,000 lux
- Compact size : W 77 × L 44 × H 24 mm
Area Sensors
Area sensors are convenient, general purpose light screens used to detect passing of objects in specified areas.
BW Series General Purpose Area Sensors
The BW series general purpose area sensors feature long sensing distance up to 7 m and are available in 22 different configurations based on the number of optics, optical pitch, and detection area size. With ambient illuminance limit of 100,000 lux, the sensors can operate error-free even under direct sunlight. Bright LED indicators are present in both the emitter and the receiver, making it easy to identify the operation status. Mutual interference prevention is possible with master/slave connection method, allowing multiple units to be installed in a row.
- Ambient illuminance : 100,000 lux (upgraded feature)
- Long sensing distance up to 7 m
- 22 configurations (number of optics : 4 to 48 / optical pitch : 20, 40 mm / detection area : 120 to 940 mm)
BWC Series Cross-Beam Area Sensors
The BWC cross-beam type area sensors utilize a 3-point cross-beam method detection to minimize non-detection area and provide reliable detection. 14 different configurations are available based on the number of optics, optical pitch, and detection area size. The sensors provide reliable detection even in areas with high ambient lighting, up to 100,000 lux. Also, the self-diagnosis output function minimizes detection error from dust or debris. The series also features various user-friendly functions including installation mode function, mutual interference prevention function, and self-diagnosis functions.
- 3-point cross-beam type detection minimizes non-detection area
- Long sensing distance up to 7 m
- 7 configurations (number of optics : 4 to 20 / optical pitch : 40, 80 mm / detection area : 120 to 1,040 mm)
BWP Series Slim Plastic Body Area Sensors
The BWP series area sensors feature a flat and compact body size (13 mm) made of high strength PC/ABS (Polycarbonate/Acrylonitrile Butadiene Styrene) plastic. The sensors use high performance Fresnel lens and have high-speed response time of under 7 ms. Four different configurations are available based on the number of optical axes and detection area size. Light ON and Dark ON operation modes switching is available. The series also features various user-friendly functions including operation test function and mutual interference prevention functions.
- Flat body (13 mm) area sensors with Fresnel lens
- High strength PC/ABS plastic body
- Light ON/Dark ON operation mode switch, operation test (emitter stop) function, mutual interference prevention function, job indicator ON/FLASHING switch
BWPK Series Slim Body Area Sensors (Picking Sensors)
The BWPK series area sensors feature a flat and compact body (10 mm) made of high strength PC/ABS (Polycarbonate/Acrylonitrile Butadiene Styrene) plastic. Picking indicators on the emitter and receiver allow clear identification of job status. Installation and wiring is made easier with the removal of synchronization wiring. DIP switches are available to switch between various functions and modes including long/short sensing distance mode, mutual interference prevention function, Light ON/Dark ON switching and picking indicator ON/FLASHING options.
- High strength PC/ABS plastic body
- Mutual interference prevention function (frequency switching)
- Sensing distance switch (long/short mode switch)
BWM Series Through-beam Mapping Sensors
The BWM series mapping sensors are optimized for glass substrate detection with double scan method and excellent optical detection performance. The sensors can detect thin glass substrates with low levels of light reflection and support CC-Link and EtherCAT communication protocols. Users can easily check the teaching area using the installation instruction mode. The mapping sensors can be used to detect display panels on transport cassettes.
- Stable glass substrate detection with using double scan method
- Sensing distance: glass G size +30%
- Customized models available: sensing channels (4 to 62 channels), optical axis pitch (25 to 200 mm)
BWML Series Line Beam Mapping Sensors
The BWML series line beam mapping sensors are optimized for glass substrate detection by using location image mapping method to minimize non-detection area and influence from harsh external conditions. The sensors support CC-Link and EtherCAT communication protocols and feature channel editing function which allows users to change pixels or edit sensing channel area with a connected PC. IP67 protection structure allows stable and error-free operation even in wet or dusty environments. The line beam mapping sensors can be used to detect display panels on transport cassettes.
- Stable glass substrate detection using line beam detection with minimal non-detection area
- Sensing distance: 95 ±10 mm
- Customized models available: sensing channels (4 to 62 channels), sensing target pitch (min. 20 mm), sensing area (280 to 1595 mm)
Proximity Sensors
Proximity sensors are common, reliable, and durable solutions for applications requiring non-contact detection.
PRFD Series Full-Metal Cylindrical Long-Distance Inductive Proximity Sensors
The PRFD series cylindrical proximity sensors feature long sensing distances and full-metal housing and sensor heads made of stainless steel 303. The robust sensors are highly resistant to deformation and corrosion and can be applied in diverse environments including food and beverage manufacturing, chemical, and metalworking industries. The metal sensor head provides high resistance to impact and wear and the 360° ring type status indicator allows users to quickly identify operation status from various angles.
- Long sensing distance
- High resistance to impact and wear caused by contact with workpieces or wire brushes (sensor head/housing: stainless steel)
- Reduced risk of malfunction caused by aluminum chips
PRF Series Full-Metal Cylindrical Inductive Proximity Sensors
The PRF series cylindrical proximity sensors feature full-metal housing and sensor head made of stainless steel 303. The robust sensors are highly resistant to deformation and corrosion and can be applied in diverse environments including food and beverage manufacturing, chemical, and metalworking industries. The 0.8 mm thick metal sensor head provides high resistance to impact and wear and the 360° ring type operation indicator allows users to quickly identify operation status from various angles.
- High resistance to impact and wear caused by contact with workpieces or wire brushes (sensor head/housing: stainless steel)
- Reduced risk of malfunction caused by aluminum chips
- 360° ring type operation indicator (red LED) (except M8 models)
PRD Series Long-Distance Cylindrical Inductive Proximity Sensors
The PRD series cylindrical inductive proximity sensors are available in standard and IO-Link communication models. The sensors feature long sensing distances and excellent noise immunity. Available in various sizes and sensing distances, the high performance cylindrical inductive sensors can be used in diverse applications requiring non-contact detection of metallic objects. The sensors also feature strain relief cables for improved flexural strength and durability.
- Operation indicator (red LED)
- Communication indicator for IO-Link model (orange, green LED)
- IP67 protection structure (IEC standard)
PR Series Cylindrical Inductive Proximity Sensors
The PR series inductive proximity sensors feature solid sensing performance, excellent noise immunity and protection circuits. Available in various sizes and sensing distances, the standard cylindrical inductive sensors can be used in diverse applications requiring non-contact detection of metallic objects.
- IP67 protection structure (IEC standard)
- Operation indicator (red LED)
- PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant models)
PS Series Rectangular Inductive Proximity Sensors
The PS series rectangular inductive proximity sensors feature excellent noise immunity and protection circuits. Various sizes and sensing sides models are available for application in diverse environments.
- Operation indicator (red LED)
- IP67 protection structure (IEC standard)
- Various sensing sides models (8 x 8 mm, 12 x 12 mm, 17 x 17 mm)
PFI Series Flat Type Rectangular Inductive Proximity Sensors
The PFI series flat type inductive proximity sensors feature excellent noise immunity. The flat, compact design with 10 mm height allows the sensors to be installed easily in applications with limited space.
- Flat, compact design (10mm height) allows easy installation in limited spaces
- Operation indicator (red LED)
- IP67 protection structure (IEC standard)
AS Series Rectangular Inductive Proximity Sensors with Long Sensing Distance
The AS series rectangular inductive proximity sensors feature long sensing distance of 50 mm and excellent noise immunity. The sensors are capable of simultaneous Normally Open + Normally Closed output, offering convenience and flexibility for users.
- Long sensing distance of 50mm
- Power supply : 12-48VDC (operating voltage : 10-65VDC)
- Simultaneous output (Normally Open + Normally Closed)
CR Series Cylindrical Capacitive Proximity Sensors
The CR series cylindrical capacitive proximity sensors are capable of detecting any material with dielectric different from air. The sensors can detect conductive and non-conductive materials including metal, iron, stone, plastic, water, and grain. The built-in sensitivity adjuster allows easy configuration of detecting distance, making it ideal for application in various environmental settings.
- Detect various materials including metal, iron, stone, plastic, water, and grain
- Built-in sensitivity adjuster for convenient configuration
- Operation indicator (red LED)
MU Series U-shaped Magnetic Proximity Sensors
The MU series U-shaped magnetic proximity sensors feature 30 mm sensing distance and are available in cable/cable connector types. The sensors can be used with BUP series photoelectric sensors for precise position control of elevators.
- Non-voltage magnetic detection method
- Two wiring specifications of cable / cable connector type
- IP67 protection structure (IEC standard)
PET18-5 Series Inductive Transmission Couplers
The PET18-5 inductive transmission couplers can be used for non-contact data transmission to various Autonics inductive proximity sensors. The couplers can be installed easily and signals can be generated and transmitted without requiring additional power. Inductive transmission couplers are applicable in various settings including drilling, robotics, automated conveyor systems, etc.
- Inductive coupling allows signals to be generated and transmitted without additional power supply
- Stable operation in various environmental settings including dust or oil
- Applications : drilling, robotics, automated conveyors system, etc.
Rotary Encoders
Rotary encoders are used to electronically monitor the position of a rotating shaft by converting shaft rotation into electronic pulses.
E58S(Sine Wave) Series 58 mm Incremental Rotary Encoders (Sine Wave, Shaft Type)
The E58S series sine wave incremental rotary encoders transmit analog sine wave operational amplifier (op-amp) output for speed regulation and position control. C, D output phase signals can be used to calculate absolute position and A, B output phase signals can be multiplied to offer high precision position control comparable to over 10,000 pulses.
- Tapered shaft
- Analog sine wave operational amplifier (op-amp) output
- Power Supply: 5 VDC ±5%
E60H(Sine Wave) Series 60 mm Incremental Rotary Encoders (Sine Wave, Hollow Shaft Type)
The E60H series sine wave incremental rotary encoders transmit analog sine wave operational amplifier (op-amp) output for speed regulation and position control. C, D output phase signals can be used to calculate absolute position and A, B output phase signals can be multiplied to offer high precision position control comparable to over 10,000 pulses.
- Ø60 mm housing, Ø20 mm hollow shaft
- Analog sine wave operational amplifier (op-amp) output
- Power Supply: 5 VDC ±5%
E15S Series 15 mm Incremental Rotary Encoders (Shaft Type)
The E15S incremental rotary encoders are ultra-compact in size (Ø15 mm) and ultra-lightweight (14 g). The small size and light weight adds flexibility for application in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The encoders have a resolution of 36 P/R and maximum allowed revolution of 3000 rpm.
- Ultra-compact (Ø15 mm) and ultra-lightweight (14 g)
- Easy installation in tight or limited spaces
- Low moment of inertia
E18S Series 18 mm Incremental Rotary Encoders (Shaft Type)
The E18S series incremental rotary encoders feature ultra-compact Ø18 mm size housings and ultra-lightweight (12 g) design. The small size and light weight allows easy installation in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The miniature encoders are ideal for small machinery including ATMs, bill counters, copy machines, and other compact-sized machinery.
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
- Ultra-compact (Ø18 mm) housing and ultra-lightweight (12 g) design
E20HB Series 20 mm Incremental Rotary Encoders (Blind Hollow Shaft Type)
The E20HB series blind hollow shaft type incremental rotary encoders feature ultra-compact Ø20 mm size housings and lightweight (35 g) design. The small size and light weight allows easy installation in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment.
- Ultra-compact (Ø20 mm) housing and lightweight (35 g) design
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
E20S Series 20 mm Incremental Rotary Encoders (Shaft Type)
The E20S series shaft type incremental rotary encoders feature ultra-compact Ø20 mm size housings and lightweight (35 g) design. The small size and light weight allows easy installation in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment.
- Ultra-compact (Ø20 mm) housing and lightweight (35 g) design
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
E30S Series 30 mm Incremental Rotary Encoders (Shaft Type)
The E30S series incremental rotary encoders feature compact Ø30 mm size housings for easy installation in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The encoders are available in various control output options.
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
- Compact Ø30 mm housing, Ø4 mm solid shaft
E40HB Series 40 mm Incremental Rotary Encoders (Blind Hollow Shaft Type)
The E40HB series blind hollow shaft type incremental rotary encoders feature Ø40 mm size housings and can be easily installed in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The encoders are available in various control output options.
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
- Blind hollow shaft type, Ø40 mm housing incremental rotary encoders
E40H Series 40 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E40H series hollow shaft type incremental rotary encoders feature Ø40 mm size housings and can be easily installed in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The encoders are available in various control output options.
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
- Hollow shaft type, Ø40 mm housing incremental rotary encoders
E40S Series 40 mm Incremental Rotary Encoders (Shaft Type)
The E40S series shaft type incremental rotary encoders feature Ø40 mm size housings and can be easily installed in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The encoders are available in various control output options.
- Easy installation in tight or limited spaces
- Low shaft moment of inertia
- Shaft type, Ø40 mm housing incremental rotary encoders
E50S Series 50 mm Incremental Rotary Encoders (Shaft Type)
The E50S series incremental rotary encoders feature Ø50 mm size housings and provide accurate measurement of angle, position, revolution, speed, acceleration, and distance. The encoders are available in cable type, cable connector type, and axial/radial connector types along with various control output options.
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
- Cable type, cable connector type, axial/radial connector types available
- Ø50 mm housing, Ø8 mm solid shaft
E58HB Series 58 mm Incremental Rotary Encoders (Blind Hollow Shaft Type)
The E58HB series blind hollow shaft type incremental rotary encoders feature Ø58 mm size flanges and provide accurate measurement of angle, position, revolution, speed, acceleration, and distance. The encoders are available in cable type, cable connector type, and axial/radial connector types along with various control output options.
- Ø58 mm flange incremental rotary encoders
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E58H Series 58 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E58H series hollow shaft type incremental rotary encoders feature Ø58 mm size flanges and provide accurate measurement of angle, position, revolution, speed, acceleration, and distance. The encoders are available in cable type, cable connector type, and axial/radial connector types along with various control output options.
- Ø58 mm flange incremental rotary encoders
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E58SC Series 58 mm Incremental Rotary Encoders (Clamping Shaft Type)
The E58SC series clamping shaft type incremental rotary encoders feature Ø58 mm size flanges and provide accurate measurement of angle, position, revolution, speed, acceleration, and distance. The encoders are available in cable type, cable connector type, and axial/radial connector types along with various control output options.
- Ø58 mm flange incremental rotary encoders
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E58SS Series 58 mm Incremental Rotary Encoders (Synchro Shaft Type)
The E58SS series synchro shaft type incremental rotary encoders feature Ø58 mm size flanges and provide accurate measurement of angle, position, revolution, speed, acceleration, and distance. The encoders are available in cable type, cable connector type, and axial/radial connector types along with various control output options.
- Ø58 mm flange incremental rotary encoders
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E60H Series 60 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E60H series incremental rotary encoders feature Ø60 mm size housings with Ø20 mm through hollow shafts. The encoders provide accurate measurement of angle, position, revolution, speed, acceleration, and distance and are available with various control output options.
- Ø60 mm housing, Ø20 mm hollow shaft
- Easy installation in tight or limited spaces
- Accurate measurement of angle, position, revolution, speed, acceleration, and distance
E68S Series 68 mm Incremental Rotary Encoders (Shaft Type)
The E68S series incremental rotary encoders feature Ø68 mm size housings with high-strength Ø15 mm solid shafts. The units can operate with radial load up to 20 kgf and thrust load up to 10 kgf. The series is ideal for operation with main shafts of machine tools. The radial connector type encoders feature IP65 protection rating for safe operation in various environments.
- Ø68 mm housing, Ø15 mm solid shaft
- 180 kHz response frequency
- IP65 protection structure (IEC standard)
E80H Series 80 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E80H series incremental rotary encoders feature Ø80 mm size housings with Ø30 mm or Ø32 mm hollow shaft sizes. The encoders provide accurate measurement of angle, position, revolution, speed, acceleration, and distance and are available with various control output options.
- Ø80 mm housing, Ø30/Ø32 mm hollow shafts
- Install directly on motors or rotating shaft. Couplings not required.
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E88H Series 88 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E88H series incremental rotary encoders with Ø88 mm size housings and Ø30 mm hollow shaft sizes are optimized for elevator systems. The encoders feature resolution of 1024 pulses per revolution and supports speeds up to 3600 rpm and 150 kHz response frequency. The encoders can be installed directly on rotating shafts of elevator winding machines without couplings.
- Ø88 mm housing, Ø30 mm hollow shaft
- Install directly on rotating shafts of elevator winding machines. No couplings required.
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
E100H Series 100 mm Incremental Rotary Encoders (Hollow Shaft Type)
The E100H series incremental rotary encoders feature Ø100 mm size housings with Ø35 mm hollow shafts. The encoders are sturdy and durable and are ideal of application in elevator systems. Various models are available by resolution and control output options.
- Ø100 mm housing, Ø35 mm hollow shaft
- Ideal for application in elevator systems
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
ENA Series Side Mount Incremental Rotary Encoders (Shaft Type)
The ENA series side mounting type incremental rotary encoders are designed to conveniently mount directly onto frames. The die-cast external housing provides excellent immunity to impact. Various resolutions are available along with various control output options.
- Various resolutions and control output options
- Designed to mount directly onto frames
- Die-cast external housing provides excellent immunity to impact
ENC Series Wheel Type Incremental Rotary Encoders
The ENC series wheel type incremental rotary encoders are ideal for measuring length or speed of continuously moving objects. The output waveform of measured distance is proportional to International Weights and Measures (meters/inches). The encoders can be applied in packaging machinery, rolling machinery, textile machinery, and other industrial machinery.
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
- Wheel type encoders ideal for measuring length or speed of continuously moving objects
- Output waveform of measured distance is proportional to International Weights and Measures (meters/inches)
EP50S Series 50 mm Single-Turn Absolute Rotary Encoders (Shaft Type)
The EP50S series single-turn absolute rotary encoders feature Ø50 mm size housings with Ø8 mm solid shafts. The single-turn absolute rotary encoders are available in various resolutions (up to 1024 divisions). The series is also available in various output codes including BCD, binary, and Gray codes. The encoders are ideal for various industrial applications requiring precise measurement, including machine tools, robotics, textile, and parking facilities.
- Ø50 mm housing, Ø8 mm solid shaft
- Various output code options: BCD, binary, Gray code
- Various resolutions (up to 1024 divisions)
EP50SP Series 50 mm Single-Turn Absolute Rotary Encoders, Plastic Housing (Shaft Type)
The EP50SP series single-turn absolute rotary encoders feature Ø50 mm size plastic housings with Ø6 mm or Ø8 mm solid shafts. The plastic housing allows flexible application in various environments. The encoders are ideal for various industrial applications requiring precise measurement, including machine tools, robotics, textile, and parking facilities.
- Ø50 mm housing, Ø6/Ø8 mm solid shaft
- Lightweight plastic housing
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
EP58HB Series 58 mm Single-Turn Absolute Rotary Encoders (Blind Hollow Shaft Type)
The EP58HB series single-turn absolute rotary encoders feature Ø58 mm size flanges with Ø8 mm blind hollow shafts. The single-turn absolute rotary encoders are available in various resolutions (up to 1024 divisions). The series is also available in various output codes including BCD, binary, and Gray codes.
- Ø58 mm flange, Ø8 mm blind hollow shaft
- Various output code options: BCD, binary, Gray code
- Various resolutions (up to 1024 divisions)
EP58SC Series 58 mm Single-Turn Absolute Rotary Encoders (Clamping Shaft Type)
The EP58SC series single-turn absolute rotary encoders feature Ø58 mm size flanges with Ø10 mm clamping shaft designs. The single-turn absolute rotary encoders are available in various resolutions (up to 1024 divisions). The series is also available in various output codes including BCD, binary, and Gray codes.
- Ø58 mm flange, Ø10 mm clamping type solid shaft
- Various output code options: BCD, binary, Gray code
- Various resolutions (up to 1024 divisions)
EP58SS Series 58 mm Single-Turn Absolute Rotary Encoders (Synchro Shaft Type)
The EP58SS series single-turn absolute rotary encoders feature Ø58 mm size flanges with Ø6 mm synchro shaft designs. The single-turn absolute rotary encoders are available in various resolutions (up to 1024 divisions). The series is also available in various output codes including BCD, binary, and Gray codes.
- Ø58 mm flange, Ø6 mm synchro type solid shaft
- Various output code options: BCD, binary, Gray code
- Various resolutions (up to 1024 divisions)
ENP Series 60 mm Single-Turn Absolute Rotary Encoders (Shaft Type)
The ENP series shaft type single-turn absolute rotary encoders feature Ø60 mm size housings with Ø10 mm solid shafts. The encoders are available in BCD code output, with various resolutions up to 360 divisions. The encoders are ideal for various industrial applications requiring precise measurement, including machine tools, robotics, textile, and parking facilities.
- Ø60 mm housing, Ø10 mm solid shaft
- Output code: BCD code
- Various resolutions: up to 360 divisions
EPM50S Series 50 mm Multi-Turn Absolute Rotary Encoders (Shaft Type)
The EPM50S series shaft type multi-turn rotary encoders feature Ø50 mm size housings with Ø8 mm solid shafts, and are available in axial and radial cable types for flexible installation. The encoders offer 23-bit (8,388,608) total resolution, with 10-bit single-turn (1,024 divisions) and 13-bit multi-turn (8,192 revolutions), and offer two output interface options, Parallel and SSI. The series also features various functions for added user convenience. The encoders are ideal for various industrial applications requiring precise measurement, including machine tools, robotics, textile, and parking facilities.
- Ø50 mm housing, Ø8 mm solid shaft multi-turn absolute rotary encoders
- 23-bit (8,388,608) total resolution: 10-bit single-turn (1,024 divisions) / 13-bit multi-turn (8,192 revolutions)
- Zero-point reset with single-turn data reset and multi-turn count reset functions
EWLS50 Series Wire-Type Linear Scale Absolute Encoders
The EWLS50 series wire type linear scale absolute encoders feature a maximum measurement range of 512 mm with resolution of 0.1 mm. The encoders also feature high accuracy of ±1/100 mm and response speed under 500 mm/sec. The series is available in binary or Gray output codes, with various functions including zero-point reset and overflow alarm (OVF).
- Resolution: 0.1 mm
- Maximum measurement range: 512 mm
- Various output code options: BCD, binary, Gray code
MGA50S Series 50 mm Magnetic Single-Turn Absolute Rotary Encoders (Shaft Type)
The MGA50S series magnetic single- turn absolute rotary encoders feature Ø50 mm size housings with Ø8 mm solid shafts. Magnetic encoders provide precision and accuracy even in harsh environments with shock, vibration, dust, or humidity (compared to optical encoders). The encoders are available in various resolutions (up to 1024 divisions) and various output codes, providing accurate, cost-efficient solutions for any demanding application.
- Longer service life compared to optical encoders
- High accuracy in harsh environments including shock, vibration, dust, and humidity (compared to optical encoders)
- Various output code options: BCD, binary, Gray
MGAM50S Series 50 mm Magnetic Multi-Turn Absolute Rotary Encoders (Shaft Type)
The MGAM50S series magnetic multi-turn absolute rotary encoders feature Ø50 mm size housings with Ø8 mm solid shafts. Magnetic encoders provide precision and accuracy even in harsh environments with shock, vibration, dust, or humidity (compared to optical encoders). The multi-turn type absolute encoders offer 23-bit (8,388,608) total resolution, with 10-bit single-turn (1024 divisions) and 13-bit multi-turn (8192 revolutions), providing accurate, cost-efficient solutions for any demanding application.
- Longer service life compared to optical encoders
- High accuracy in harsh environments including shock, vibration, dust, and humidity (compared to optical encoders)
- Output interface options: Parallel, SSI (Synchronous Serial Interface)
ENH Series Manual Handle Type Incremental Encoders
The ENH series manual handle type incremental rotary encoders are ideal for manual pulse input applications including NC machinery and milling machines. The terminal connection type encoders can be applied in various machine tools.
- Terminal connection type
- Power supply: 5 VDC ±5%, 12-24 VDC ±5%
- Ideal for manual pulse input applications including NC machinery and milling machines
ENHP Series Portable Manual Handle Type Incremental Encoders
The ENHP series portable manual handle type incremental rotary encoders are ideal for manual pulse input applications including NC machinery and milling machines. The encoders can be easily connected/disconnected with the D-sub connector.
- Emergency stop switch, enable operation switch
- 6-position axis selector switch, 4-position rate selector switch
- Ideal for manual pulse input applications including NC machinery and milling machines
ERB Series Flexible Shaft Couplings
The ERB series flexible couplings are high-strength aluminum alloy (AL7075-T6) beam couplings with high elasticity. The couplings have zero backlash, providing accurate transmission of torque between shafts. The surface is treated with alumite for high corrosion resistance. The ERB series is available in clamp type and screw type connection and Ø19 mm and Ø26 mm outer diameter sizes.
- Alumite treated surface provides high corrosion resistance
- 2 connection types (clamp type, screw type)
- High-strength aluminum alloy (AL7075-T6)
For more information about these products…
Download a Catalog
