Straight Hose
Coilhose Pneumetics offers several of the most common plastic tubing used in industrial and pneumatic applications. Each thermoplastic compound exhibits different characteristics that need to be taken into consideration when selecting tubing for any application.
Becoming familiar with the different features and advantages of each tubing compound will be most beneficial in the selection process.
Discover Coilhose Pneumatics Straight Hose for Durable, Reliable Compressed Air Connections
Flexeel® Hose
A Lightweight Alternative to Bulky Rubber Hose.
Flexeel® Reinforced Polyurethane Hose offers an excellent alternative to bulky rubber hose. This hose is extremely lightweight and is extruded with an inner-layer, a layer of reinforced braiding, and an outside jacket. This extrusion process yields an “integral piece” that ensures the integrity of the hose over long periods of use. All of this yields a strong, durable hose with an increased working pressure.
- Constructed of Lightweight, Tough Reinforced Polyurethane
- Temperature Range: -40°F to +165°F
- 200 psi Working Pressure
- Made in USA
Flexeel® with Quick Connect Fittings
These hoses are equipped with quick connect fittings, and allow for in-field repairs of damaged hose sections.
- Equipped with Quality Couplers & Connectors
- High Quality Brass Fittings Provide Strong & Durable Connection
- Ends are Completely Field Repairable
Flexeel® with Reusable Strain Relief Fittings
These hoses are equipped with reusable strain relief fittings that allow for in-field repairs of damaged hose sections. Flexeel Strain Relief Fittings maintain the hose’s diameter, providing full flow at even a 180° bend.
Furthermore, Flexeel® Strain Relief Fittings feature an integral brass insert that is part of the injection molding process. This means that the brass insert is a permanent part of the strain relief.
- High Quality Brass Fittings Provide Strong & Durable Connection
- Strain Relief Fittings are Completely Field Repairable
Flexeel® with Reusable Fittings
These hoses are equipped with reusable brass fittings, and allow for in-field repairs of damaged hose sections.
- High Quality Brass Fittings Provide Strong & Durable Connection
- Fittings are Completely Field Repairable
Flexeel® without Fittings
These hoses are not equipped with fittings, allowing for custom assemblies by the end-user.
- Without Fittings, Ready for Custom Assembly by End-User
Flexeel® CoBlo™ Hose
The new Hi-Viz Orange Flexeel® comes equipped with the Industrial CoBlo™ Coupler Blow Gun and a connector, and allows for in-field repairs of damaged hose sections.
Flexeel® Reinforced Polyurethane Hose offers an excellent alternative to bulky rubber hose. This hose is extremely lightweight and is extruded with an inner-layer, a layer of reinforced braiding, and an outside jacket. This extrusion process yields an “integral piece” that ensures the integrity of the hose over long periods of use. All of this yields a strong, durable hose with an increased working pressure.
- Constructed of Lightweight, Tough Reinforced Polyurethane
- Temperature Range: -40°F to 165°F
- Flexeel: 200 psi Working Pressure; CoBlo: 120 psi Working Pressure
- High Quality Industrial CoBlo – Six Ball Coupler with a Built-in Blow Gun & Connector
- Works with Tool Connected or Disconnected
- Ends are Completely Field Repairable
- OSHA Compliant – Recessed Outlet Cannot be Dead-ended
Flexeel Max® Hose
The Flexeel Max® Adds Additional Features to the Flexeel® Reinforced Polyurethane Hose.
- Ball Swivel and the popular Six Ball Coupler on a Reusable Strain Relief
- Safety Relief Plug on a Reusable Strain Relief
- Eel-Strap™, Making Storage Easier
- Hi-Viz Eel Green Color Makes Flexeel Max® Easy to See
- Constructed of Reinforced Polyurethane
- Temperature Range: -40°F to +165°F
- Higher working pressure of 300 psi
- Made in USA
Yellow Belly™ Hose
- Features a Flexible Hybrid PVC Construction
- Lays Flat, Even in Cold Environments
- Easy Roll out and Storage
- Resists Kinking
- Temperature Range: -40°F to +140°F
- 300 psi Working Pressure
- High Quality Brass Fittings Provide Strong & Durable Connection
Thermoplastic Hose
A PVC based hose that provides an Increased Working Pressure and Oil Resistance.
Thermoplastic Hose combines PVC with special additives that increase its working pressure along with enhancing resistance to oils. Equipped with a PVC inner tube, reinforcement braiding, and a tough jacket, this hose is perfect for industrial environments.
Heavy Duty Neoprene Hose
Heavy-Duty Neoprene Hose is for use with air or water. It has a tough nitrile inner tube, textile reinforcement, and neoprene outer jacket provides flexibility and a high oil-resistance.
- Features a Tough, Oil Resistant Neoprene Cover
- Temperature Range: -40°F to +212°F
- 200 psi Working Pressure
- Electrically Non-Conductive
- Made in USA
Neoprene Hose with Fittings
This hose is available with reusable fittings, or crimped on hose fittings.
- High Quality Brass Fittings Provide Strong & Durable Connection
Neoprene Hose without Fittings
General Purpose Rubber Hose
General Purpose Rubber Hose is best for use in industrial environments or construction sites where contact with petroleum products is minimal.
The General Purpose hose features a black EPDM rubber inner tube, textile reinforcement, and an attractive red EPDM rubber cover. This is commonly known as a “red rubber hose.”
- Features a Red, EPDM Rubber Jacket
- Temperature Range: -40°F to +212°F
- 200 psi Working Pressure
- Made in USA
Rubber Hose with Fittings
General Purpose Rubber Hose is available with crimped-on or reusable fittings.
- High Quality Brass Fittings Provide Strong & Durable Connection
Rubber Hose without Fittings
Lock-On Series Hose
Lock-On Hose offers an increased working pressure, and the ability to quickly assemble or repair hoses. Lock-On Hose consists of a black nitrile inner tube, textile reinforcement spirals, and a gray Neoprene outer jacket.
These hoses are not equipped with fittings, allowing for custom assembly by the end-user. Lock-On Hose does not require hose clamps, ferrules, or crimpers to assemble. When pressurized, Lock-On Hose contracts and elongates slightly, gripping the fitting.
- Equipped without Fittings for Assembly by the End-User (RMA Class A)
- Gray Neoprene Cover Resists Oil and Abrasion
- Temperature Range: -40°F to +212°F
- 300 psi Working Pressure
- Eliminates the Need for Ferrules and Clamps
- Made in USA
Garden Hose
Garden Flexeel® features standard 3/4 inch garden hose threads and is approximately 1/2 inch diameter OD. Garden Flexeel® is equipped with reusable strain relief fittings that allow for in-field repairs of damaged hose sections. Flexeel® Strain Relief Fittings maintain the hose’s diameter, providing full flow at even a 180° bend.
Furthermore, Flexeel® Strain Relief Fittings feature an integral brass insert that is part of the injection molding process. This means that the brass insert is a permanent part of the strain relief.
FEATURES
- Reinforced Polyurethane Provides Lightweight and Flexibility
- Equipped with Reusable Strain Relief Fittings
- Broad Temperature Range
- Made in USA
Gilaflex® Hose
A Reinforced PVC Air Hose with a High Working Pressure.
Flexflow® Hose
Optimal for Lubrication and Cooling Applications.
For more information about this product…
