Drivers & Controllers

<< Back to Enfield page

Product Lineup

Drivers

D-1Enfield Technologies Drivers

The D1 PWM Valve Driver is designed specifically to drive and manage Enfield Technologies proportional valves. It converts a proportional command voltage into a -1.1…1.1A current signal to drive the valve’s linear force motor (different from a solenoid valve).

Power Requirements: 12 or 24 Vdc @ 15 W
Input: Selectable: 0…5Vdc or 0…10Vdc, PWM > 2kHz frequency
Output: -1.1A…1.1A
Temperature Range: -40°C to 65°C (-40°F to 150°F)

Controllers

LS-C10

Enfield Technologies Controllers LS-C10
Control Type: P with Aux
Power Requirements: ±12 Vdc @ 25W (LS Valves), ±15 Vdc @ 30W (M2 Valves)
Command Signal Input: ±10 Vdc Range (0-10 Vdc typ.) 4-20 mA
Feedback Signal Input: ±10 Vdc Range (0-10 Vdc typ.) 4-20 mA
Dimensions: 166 x 111 x 55 mm

LS-C41

Enfield Technologies Controllers LS-C41
Control Type: PID with FF and Aux
Power Requirements: 18-36 Vdc 24 Vdc Nom. @ 30W
Command Signal Input: ±10 Vdc Range (0-10 Vdc typ.)
Feedback Signal Input: ±10 Vdc Range (0-10 Vdc typ.)
Dimensions: 137 x 126 x 45 mm

C1

Control Type: PID or P with Ramp selectable
Power Requirements:+12…24 Vdc, 24 Vdc nominal @ 20W
Command Signal Input: 0-10Vdc or 4-20mA
Feedback Signal Input: 0-10Vdc or 4-20mA
Dimensions: 46 x 56 x 45 mm
