Power Electronics
Power electronics, including switching mode power supplies, solid state relays, and power controllers, help maintain stable and efficient power supply.
Discover Autonics Power Electronics for Reliable Power Control and Switching
SMPS
Switching mode power supplies are electronic power supplies which convert electrical power efficiently using a switching regulator.
SPB-A Series DIN Rail Switching Mode Power Supplies
The SPB-A series switching mode power supplies allows space-saving installation with a slim and compact design. The SPB- A series also features easy and secure connection with rising clamp type terminals.
The switching mode power supplies offer stable performance over a wide temperature range. The series features excellent environmental resistance with overcurrent/overvoltage protection and overheating prevention functions.
- Various lineups for diverse applications (15W~480W)
- Compact size for maximum space efficiency
- Improved power factor with PFC circuit
- Outstanding environmental resistance: overcurrent/overvoltage protection and overheating prevention, wide temperature range
- Low output voltage indicator (red LED), output indicator (green LED)
- Simple and easy installation
SPA Series Panel Mount Switching Mode Power Supplies
The SPA series switching mode power supplies provide efficient power conversion and stable power supply with minimal noise and ripple. Various output voltage (5 VDC, 12 VDC, 24 VDC) and output power (30 W, 50 W, 75 W, 100 W, 400 W) models are available for diverse applications.
The SPA series also features built-in overcurrent protection circuit, output short-circuit protection circuit, overheat protection circuit, and overvoltage protection circuits.
- Stable power supply with minimal noise and ripple
- Output voltage: 5 VDC, 12 VDC, 24 VDC
- Output power: 30 W, 50 W, 75 W, 100 W
SP Series DIN Rail Switching Mode Power Supplies (3W)
The SP series simple type switching mode power supplies feature compact sizes with 3 W output power. 5 VDC, 12 VDC, and 24 VDC output voltage options are available. The units can be clipped on to DIN rails or mounted using standard M4 sized screws for convenient installation. The SP series also feature built-in overcurrent (short-circuit) protection circuits.
- Compact size and high performance
- Built-in overcurrent protection circuit
- DIN rail mount and screw mount methods
SPB Series DIN Rail Switching Mode Power Supplies
The SPB series switching mode power supplies offer high power conversion efficiency and stable power supply with low noise and ripple and minimal heat generation. The switching mode power supplies can be easily clipped onto DIN rails or mounted using screws.
The slim and compact design also allows space-saving installation. The series also features various safety and user-friendly features including terminal protection covers (SPB-060/120/180/240) and rising clamp type terminals (SPB-015/030). Various output power models are available for application in diverse environments.
- Efficient power conversion
- Space efficient design
- Safety and user-friendly features
Solid State Relays
Solid state relays (SSR) are highly durable and reliable electronics switching devices which are ideal alternatives for mechanical relays.
SR1 Series Single-Phase Solid State Relays (Detachable Heatsink Type)
The SR1 series single phase solid state relays feature compact, universal designs for flexible installation and detachable heatsinks for easier maintenance or replacement.
The solid state relays provide durable and stable control, for optimal performance in various applications including heater loads, semiconductor equipment, and motor control.
- Compact, universal design for flexible installation
- High heat dissipation efficiency with ceramic PCB
- Zero cross turn-on, random turn-on models available
SRH1 Series Single-Phase Solid State Relays (Integrated Heatsink, Top/Bottom Terminal Type)
The SRH1 series single phase solid state relays feature integrated heatsinks for excellent heat dissipation efficiency, and the standard top/bottom terminal layout allows easy installation. The voltage input type models are available in zero cross turn-on and random turn-on models.
The current input type models offer both phase control (equal power/equal phase) and cycle control (fixed/variable) options. The units support both DIN rail mount and panel mount methods for easy installation.
- High heat dissipation efficiency with ceramic PCB
- Input indicator (green LED)
- DIN rail mount or panel mount installation
SRHL1 Series Single-Phase Solid State Relays (Integrated Heatsink, Left/Right Terminal Type)
The SRHL1 series single phase solid state relays feature integrated heatsinks for excellent heat dissipation efficiency. The left/right terminal layout provides more flexible installation options.
The SRHL1 series is available in zero cross turn-on and random turn-on models, and also feature alarm functions for safer operation. The units support both DIN rail mount and panel mount methods.
- Rated input voltage : 10-30 VDC, 90-240 VAC
- Rated load voltage : 24-240 VAC, 48-480 VAC
- Rated load current : 10 A, 15 A, 20 A, 25 A, 40 A
SRC1 Series Single-Phase Solid State Relays (Slim, Detachable Heatsink Type)
The SRC1 series single phase solid state relays feature slim and compact design (22.5 mm width) for flexible installation and detachable heatsinks for easy maintenance or replacement.
The solid state relays provide durable and stable control, for optimal performance in various applications including heater loads, semiconductor equipment, and motor control.
- Slim, compact size (22.5mm width)
- High heat dissipation efficiency with ceramic PCB
- Zero cross turn-on, random turn-on models available
SRS1 Series Single-Phase Solid State Relays (Socket Type)
The SRS1 series socket type single phase solid state relays offer easy installation and maintenance. The high dielectric strength of 2500 VAC and diverse power options provide durable and reliable performance in various applications, including heater loads, semiconductor equipment, and motor control.
- Socket type for easier installation and maintenance
- Dielectric strength: 2500 VAC
- Zero cross turn-on, random turn-on models available
SR2/3 Series Three-Phase Solid State Relays (Detachable Heatsink Type)
The SR2/3 series three-phase solid state relays are detachable heatsink types, which can be used with various heatsinks. The solid state relays can control 2-phase or 3-phase loads and feature two mounting hole types for compatibility with various types of heatsinks.
The series also features alarm output for safe operation, and are also available in 24 VAC low voltage models. Select models feature high dielectric strength of up to 4000 VAC.
- Two mounting hole types and sizes
- Alarm (overheating) function: alarm output indicator (red LED), disconnect standard output, alarm output
- High heat dissipation efficiency with ceramic PCB and integrated heatsink
SRH2/SRH3 Series Three-Phase Solid State Relays (Integrated Heatsink Type)
The SRH2/3 series three-phase solid state relays are integrated heatsink types, which are removable. The solid state relays can control 2-phase or 3-phase loads and feature two mounting hole types for compatibility with various types of heatsinks.
The series also features alarm output for safe operation, and are also available in 24 VAC low voltage models. Select models feature high dielectric strength of up to 4000 VAC and integrated heatsink models can be mounted on to both DIN rails and panels.
- Two mounting hole types and sizes
- Alarm (overheating) function: alarm output indicator (red LED), disconnect standard output, alarm output
- High heat dissipation efficiency with ceramic PCB and integrated heatsink
Power Controllers
Power controllers are used to control the amount of electric currents in devices such as heaters, furnaces, thermostats, or motors.
SPRS Series Modular Multi-Channel Power Controllers
The SPRS series modular multi-channel power controllers combine control modules and power modules to accurately control temperature of heating machinery.
Efficient power control is possible with power distribution control function for up to 36 units. Various control methods and alarm functions are also available.
- Modular power controllers with separate control and power modules
- Connect up to 4 power modules to a single control module
- Various rated current models : 25A to 600A
SPRM Series Multi-channel Power Controllers
The SPRM series multi-channel power controllers offer single-phase and three-phase control. The 4-line LCD display allows real-time monitoring of load current, load voltage, load power and heat-sink temperature.
The controllers feature open/close structure for convenient fuse replacement and cycle control, phase control, feedback control (constant current, constant voltage, constant power) methods are available for stable power control. RS485 and EtherCAT communication are also supported.
- Single-phase control or three-phase control selectable
- Wide voltage range : 220 to 440 VAC
- Various rated current models : 25 / 40 / 55 / 70 / 90 / 110 / 160 A
SPR3 Series Slim Three-Phase Power Controllers with LED Display
The SPR3 series three-phase power controllers are ideal for installation in limited spaces with slim body sizes measuring only 105 mm wide. The LED display allows real-time monitoring of control input, load voltage, load current, load power, load resistance, and heat-sink temperature.
The controllers feature phase control, cycle control, and ON/OFF control methods, with feedback control (constant current, constant voltage, constant power) option available for accurate and stable power control. With high power efficiency, the three-phase power controllers are ideal for various environments including power transmission and electric power distribution.
- Slim and elegant design
- LED display allows real-time monitoring of control input, load voltage, load current, load power, load resistance, and heat-sink temperature
- Stable control with feedback control (constant current, constant voltage, constant power)
SPR1 Series Slim Single-Phase Power Controllers with LED Display
The SPR1 series single-phase power controllers are ideal for installation in limited spaces with slim body sizes measuring only 55 mm wide. The LED display allows real-time monitoring of control input, load voltage, load current, load power, load resistance, and heat-sink temperature.
The controllers feature phase control, cycle control, and ON/OFF control methods, with feedback control (constant current, constant voltage, constant power) option available for accurate and stable power control.
- Slim and elegant design
- LED display allows real-time monitoring of control input, load voltage, load current, load power, load resistance, and heat-sink temperature
- Stable control with feedback control (constant current, constant voltage, constant power)
DPU Series Digital Power Controllers
The DPU series digital power controllers offer optimal and stable power control with minimal noise interference. The units also feature various control methods and functions including soft start, soft up/down, and alarm.
- High speed and high accuracy by digital control using high speed CPU
- Various controls
- Improved maintainability with built-in fast-acting fuse and easy fuse replacement
SPC1 Series Single-Phase Power Controllers
The SPC1 series single phase power controllers offer reliable and stable power control. The units can handle various control inputs and feature various control modes (phase control, cycle control, ON/OFF control).
The controllers also feature various functions including output adjustment function and soft start function. Users can also quickly identify operation status with the LED output operation indicator.
- Various control inputs
- Various functions & features: output adjustment, soft start, operation indicator, etc.
- Rated load current: 35 A, 50 A
AK-RB Series 5-Phase Stepper Motors with Built-in Brakes (Rotary Actuator Type)
The AK-RB series rotary actuator type 5-phase stepper motors are ideal for applications requiring high torque. The AK-RB series offer great cost efficiency with its low, economical prices and also feature built-in brakes for improved convenience. The brakes are released when 24 VDC power is applied to the brake wires.
- Compact, space-saving design ideal for building compact-sized systems
- Built-in brakes (brake is released when 24 VDC power is applied to brake wire)
- Backlash (frame size): 60 mm: ±20’ (0.33°)
MD5 Series 5-Phase Stepper Motor Drivers
The MD5 series 5-phase stepper motor drivers allow extremely precise motor control with low mechanical noise and low vibration operation. The isolated photocoupler input design minimizes influence from electrical noise. The motors also feature various built-in functions including auto current down and self-diagnosis. The microstepping drive models offer low-speed rotation and extreme precision with up to 250 division control.
- Bipolar constant current pentagon drive method
- Various built-in functions including auto current down and self-diagnosis
- Microstepping drive allows low-speed rotation and extreme precision control (MD5-HD14, MD5-HF14, MD5-HF14-AO, MD5-HF28)
Closed Loop Stepper (Ai-SERVO)
Closed loop stepper motor packages consist of motors with integrated encoders for feedback and higher precision control.
AiC-MT Series Modbus TCP Comm. Type 2-Phase Closed Loop Stepper Motor System
The AiC-MT series closed-loop stepper motors with Ethernet based Modbus TCP communication offer high compatibility between primary and secondary devices and can control up to 254 axes.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Ethernet based Modbus TCP protocol
- Control up to 254 axes with Modbus TCP communication, with daisy-chaining method LAN connection (2 Port
- Ethernet switching hub included)
- Windows-based software (atMotion) for easy parameter setting and monitoring
- 7-segment display for alarm/status reading
- Built-in brake type motors available
- Built-in gear/rotary actuator type motors available
AiC-D-MT Series Modbus TCP Comm. Type 2-Phase Closed Loop Stepper Motor Drivers
The AiC-D-MT series closed-loop stepper motor drivers with Ethernet based Modbus TCP communication offer high compatibility between primary and secondary devices and can control up to 254 axes.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Ethernet based Modbus TCP protocol
- Control up to 254 axes with Modbus TCP communication, with daisy-chaining method LAN connection (2 Port Ethernet switching hub included)
- Windows-based software (atMotion) for easy parameter setting and monitoring
- 7-segment display for alarm/status reading
- Built-in brake/gear/ rotary actuator type motors available
AiCA-EC Series AC Power EtherCAT Comm. Type 2-Phase Closed Loop Stepper Motor System
The AiCA-EC series Ai-SERVO closed-loop stepper motors with EtherCAT support offers high compatibility between primary and secondary devices with EtherCAT open protocol. The motor system can control motion of multiple axes simultaneously with 100 Mbps communication speed. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiC-EC Series EtherCAT Comm. Type 2-Phase Closed Loop Stepper Motor System
The AiC-EC series Ai-SERVO closed-loop stepper motors with EtherCAT support offers high compatibility between primary and secondary devices with EtherCAT open protocol. The motor system can control motion of multiple axes simultaneously with 100 Mbps communication speed.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Multi-axis simultaneous control with EtherCAT communication
AiA-M-G/R Series Built-in Gear / Rotary Actuator Type AC Power Input 2-Phase Closed Loop Stepper Motors
The AiA-M-G/R series AC power input 2-phase closed loop stepper motors with built-in gear/rotary actuator type are available in □ 60 mm, □ 86 mm frame sizes. The AiA-M-G/R series motors are ideal for high torque in a small space with compact size. The built-in rotary actuator types are ideal for ease of use and durability when connecting loads.
- Built-in planetary gear type motor (AiA-M-G)
- Built-in rotary actuator type motor (AiA-M-R)
- Frame sizes : □ 60 mm, □ 86 mm
Ai-M-G/R Series Built-in Gear / Rotary Actuator Type 2-Phase Closed Loop Stepper Motors
The Ai-M-G/R series 2-phase closed loop stepper motors with built-in gear/rotary actuator type are available in □ 42 mm, □ 60 mm frame sizes. The Ai-M-G/R series motors are ideal for high torque in a small space with compact size. The built-in rotary actuator types are ideal for ease of use and durability when connecting loads.
- Built-in planetary gear type motor (Ai-M-G)
- Built-in rotary actuator type motor (Ai-M-R)
- Frame sizes : □ 42 mm, □ 60 mm
AiSA Series AC Power 2-Phase Closed Loop Stepper Motor System
The AiSA series Ai-SERVO motors are AC powered 2-phase closed loop stepper motor system featuring integrated drivers. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies. The automatic current down function reduces the electric current when the motor stops (load change) to minimize heat generation.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiCA Series AC Power 2-Phase Closed Loop Stepper Motor System with Integrated Controllers
The AiCA series Ai-SERVO motors are AC powered 2-phase closed loop stepper motor system featuring integrated drivers and controllers. The motor system can control motion of multiple axes directly with network communication. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiC-CL Series CC-Link Type 2-Phase Closed Loop Stepper Motor System
The AiC-CL series Ai-SERVO motors feature support for CC-Link communication. The motors can be used with Mitsubishi PLCs through CC-Link communication, offering easy connection, installation, and control without additional modules or controllers. Up to 42 axes can be controlled simultaneously or independently.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Control up to 42 axes with CC-Link communication
AiC Series 2-Phase Closed Loop Stepper Motor System with Integrated Controllers
The AiC series Ai-SERVO motors are 2-phase closed loop stepper motor system featuring integrated drivers and controllers. The motor system can control motion of multiple axes directly with network communication. The provided atMotion software allows easy control settings and status monitoring.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Motor driver + integrated controller type
AiS Series 2-Phase Closed Loop Stepper Motor System
The AiS series Ai-SERVO motors are pulse control closed loop stepper motor system offering accurate and precise position control through feedback from integrated encoders. The motors feature quick response rates for ideal short pitch drive. Gain tuning is easy with the external gain adjuster.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Easy operation setting with external adjuster (Gain, speed filter, in-position, resolution)
AiCA-D-EC Series AC Power EtherCAT Comm. Type 2-Phase Closed Loop Stepper Motor Drivers
The AiCA-D-EC series Ai-SERVO closed-loop stepper motor drivers with EtherCAT support offers high compatibility between primary and secondary devices with EtherCAT open protocol. The motor system can control motion of multiple axes simultaneously with 100Mbps communication speed. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiC-D-EC Series EtherCAT Comm. Type 2-Phase Closed Loop Stepper Motor Driver
The AiC-D-EC series Ai-SERVO closed-loop stepper motor drivers with EtherCAT support offers high compatibility between primary and secondary devices with EtherCAT open protocol. The motor system can control motion of multiple axes simultaneously with 100Mbps communication speed.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Multi-axis simultaneous control with EtherCAT communication
AiSA-D Series AC Power 2-Phase Closed Loop Stepper Motor Drivers
The AiSA-D series Ai-SERVO motor drivers are AC powered 2-phase closed loop stepper motor drivers. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies. The automatic current down function reduces the electric current when the motor stops (load change) to minimize heat generation.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiCA-D Series AC Power 2-Phase Closed Loop Stepper Motor Drivers with Integrated Controllers
The AiCA-D series Ai-SERVO motor drivers are AC powered 2-phase closed loop stepper motor drivers. The drivers can control motion of multiple axes directly with network communication. The AC powered motor system can maintain higher torque during high speed drive compared to DC type motors and do not require separate switching mode power supplies.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Supports 200-240 VAC AC power supply
AiC-D-CL Series CC-Link Type 2-Phase Closed Loop Stepper Motor Drivers
The AiC-D-CL series Ai-SERVO motor drivers feature support for CC-Link communication. The drivers can be used with Mitsubishi PLCs through CC-Link communication, offering easy connection, installation, and control without additional modules or controllers. Up to 42 motor axes can be controlled simultaneously or independently.
- Closed-loop system with real-time position control
- High speed and high torque drive without missed steps
- Control up to 42 axes with CC-Link communication
AiC-D Series 2-Phase Closed Loop Stepper Motor System with Integrated Controllers
The AiC-D series Ai-SERVO motors drivers are 2-phase closed loop stepper motor drivers with integrated controllers. The drivers can control motion of multiple axes directly with network communication. The provided atMotion software allows easy control settings and status monitoring.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Motor driver + integrated controller type
AiS-D Series 2-Phase Closed Loop Stepper Motor Drivers
The AiS-D series Ai-SERVO motors drivers are pulse control closed loop stepper motor drivers offering accurate and precise position control through feedback from motor integrated encoders. The drivers feature quick response rates for ideal short pitch drive. Gain tuning is easy with the external gain adjuster.
- Closed loop system for precise real-time position control
- High speed and high torque drive without missed steps
- Easy operation setting with external adjuster (Gain, speed filter, in-position, resolution)
AiA-M-B Series AC Power 2-Phase Closed Loop Stepper Motors with Built-in Brakes
The AiA-M-B series 2-phase closed loop stepper motors with built-in brakes are ideal for controlling vertical loads. The AiA-M-B series motors are available in 60 mm, and 86 mm frame sizes.
- Brakes are released when power is applied to the brake wire
- Frame sizes: 60 mm, 86 mm
- Compatible motor driver: AiSA-D, AiCA-D Series
AiA-M Series AC Power 2-Phase Closed Loop Stepper Motors
The AiA-M series AC powered 2-phase closed loop stepper motors maintain higher torque during high speed drive compared to DC powered motors The AiA-M series is available in 60 mm and 86 mm frame sizes.
- Frame sizes: 60 mm
- Frame sizes: 86 mm
- Compatible motor driver: AiSA-D, AiCA-D Series
Ai-M Series 2-Phase Closed Loop Stepper Motors
The Ai-M series 2-phase closed loop stepper motors feature integrated encoders for precise feedback control. The Ai-M series motors are available in 20 mm, 28 mm, 35 mm, 42 mm, 56 mm, and 60 mm frame sizes.
- Frame sizes: 20 mm, 28 mm, 35 mm, 42 mm, 56 mm, 60 mm
- Compatible motor driver: AiS-D, AiC-D, AiC-D-CLSeries
Ai-M-B Series 2-Phase Closed Loop Stepper Motors with Built-in Brakes
The Ai-M-B series 2-phase closed loop stepper motors with built-in brakes are ideal for controlling vertical loads. The Ai-M-B series motors are available in 42 mm, 56 mm, and 60 mm frame sizes.
- Brakes are released when power is applied to the brake wire
- Frame sizes: 42 mm, 56 mm, 60 mm
- Compatible motor driver: AiS-D, AiC-D, AiC-D-CL Series
Have a Challenge? Let’s Find the Right Automation Solution.
Need help replacing a component, improving machine performance, or choosing the right product for your application? All Air Inc. helps customers solve pneumatic automation, motion control, sensing, machine safety, robotics, and industrial equipment challenges with trusted manufacturer partnerships, technical product knowledge, and responsive application support.
