Reciprocating Compressors

<< Back to Champion page

Champion air-cooled reciprocating pumps and air compressor packages can be used to match the needs of a wide variety of compressor applications. Champion has air compressors designed for home use to air compressors that are used for plant air service. Champion reciprocating air compressors are well suited for many applications.

Product Lineup

Advantage Series

Champion Pneumatic Advantage
The Advantage Series units come fully packaged with pre-installed accessories. They are highlighted by our quick-ship program so the compressor arrives quickly, ready to install and operate. Each new assembled unit has a 3-year warranty on the compressor pump.

  • 5 – 25 hp
  • Maximum Pressure Up to 175 psig
  • 16.5 – 90.1 acfm at 175 psig
  • Two Stage, Splash Lubricated
  • Tank Mounted, Simplex and Duplex Models
  • Vertical or Horizontal Configurations
  • Package comes standard with up to six pre-installed options
  • Factory filled with ChampLub lubricant

R-Series

Champion Pneumatic R-Series
Champion R-Series Compressors have a time-tested, proven design. Rugged standard features, a wide selection of configurations, and quality available options make the R-Series compressors the solution to your application. Delivering high performance, long life and tremendous value. Champion compressors are the proven choice!

  • 2 – 30 HP
  • Up to 175 PSIG
  • 4.2 – 202 ACFM at 175 PSIG on electric driven units
  • Gas and diesel engine drive models available
  • Tank or Base Mounted, Simplex & Duplex Models
  • Two Stage Splash-Lubricated Pumps
  • 3-year Pump Warranty and 1-year Package Warranty
  • Factory filled with ChampLub lubricant
  • Load-less starting (via centrifugal unloader) for lower energy costs and less wear on drive motor
  • ASME inter-stage pressure relief valve for protection
  • ODP NEMA 1760 RPM electric motor
  • 10 Micron industrial grade intake filter
  • ASME coded receiver
  • 0-300 PSIG air pressure gauge on tank
  • Available voltages
    • Single phase-115/208-230
    • Three phase-208/230/460/575

PL-Series

Champion Pneumatic PL-Series
Champion PL-Series pressure lubricated compressors have a time-tested, proven design. Rugged standard features, a wide selection of configurations, and quality available options make the PL-Series compressors the solution to your application. They deliver high performance, long life and tremendous value. Champion compressors are the proven choice.

  • 3 – 30 hp
  • Up to 250 psig
  • 9.7 – 202 acfm at 175 psig on Electric Driven units
  • Tank or Base Mounted, Simplex, Duplex and Engine Driven Models
  • Two-Stage pressure lubricated pumps
  • Loadless auto stop/start
  • 3-year Pump Warranty and 1-year Package Warranty
  • Factory filled with AEON lubricant
  • Load-less starting (via hydraulic unloader) for lower energy costs and less wear on drive motor
  • ASME inter-stage pressure relief valve for protection
  • ODP NEMA 1760 RPM electric motor
  • 10 Micron industrial grade intake filter
  • ASME coded receiver
  • 0-300 PSIG air pressure gauge on tank
  • Available voltages
    • Single phase-115/208-230
    • Three phase-208/230/460/575

Engine Driven

Champion Pneumatic Engine Driven
Champion is the leader in manufacturing dependable compressed air systems. Champion offers a complete line of engine driven compressor packages from 9.1-22.5 horsepower to meet any application. With an engine driven package, there is no need to worry about electrical service. Engine driven air compressors were designed to provide compressed air in remote locations or for emergency production line needs.

  • 9.1-22.5 HP
  • Two Stage Compressor Pump
  • Available in Splash or Pressure Lubrication
  • 3-year Pump Warranty and 1-year Package Warranty
  • ASME & CRN Certified 30, 60, 80 Gallon Horizontal Air Receivers
    • Manual Receiver Drain Valve
    • Pressure Relief Valve
    • Service Valve
    • Pressure Gauge
    • 30 Gallon Receivers Include Vibration Isolators
    • Belt Driven
  • Electric Start
  • Totally Enclosed Belt Guard
  • Oil Level Sight Glass

Evolution

Champion Pneumatic Evolution
Champion Evolution Compressors provide the advantages of a reciprocating compressor coupled with less noise and vibration. Loaded with rugged features, these compressors deliver high performance and tremendous value. As a result, Evolution compressors offer long, trouble-free service with maximum operating efficiency.

  • 5, 7.5, 10 & 15 HP
  • Pressure at 175 PSIG
  • 16.8 – 46.6 CFM
  • Noise level as low as 66 dBA
  • Tank or Base Mounted
  • Two Stage, Splash-Lubricated
  • 3-year Pump Warranty and 1-year Package Warranty
  • Factory filled with ChampLub
  • Magnetic starter for thermal overload protection
  • Manual tank drain
  • Standard start/stop control
  • Sound attenuating enclosure for low noise operation
  • Ball valve on crankcase drain for easy maintenance of lubricant
  • Front and back panels can be easily removed for fast and easy service access
  • Air intake pre-filterPackage easily fits through a standard 36″ door
  • 80/20 duty cycle
  • Low oil-level shutdown

Centurion II

Champion Pneumatic Centurion II
The Champion Centurion II compressor is engineered to deliver industrial-rated dependability at an affordable price. The RV line offers maximum installation versatility. Each compressor features durable cast-iron construction, industrial grade filter and silencer and alloy steel reed valves.

  • 2-15 HP
  • 125-175 PSIG
  • 4.9-49 CFM at 175 PSIG rating
  • Tank Mounted, Vertical or Horizontal Configuration
  • Two-Stage, Splash Lubricated Compressor Pump
  • Automatic Start/Stop Operation
  • Factory filled with ChampLub AC lubricant
  • 13 HP gas engine compressor/generator model available
  • Automatic Start/Stop Operation
  • Magnetic Starter*
  • ASME Coded Receiver
  • NEMA Rated Electric Motors
  • 0-300 PSIG Air Pressure Gauge on Tank
  • Preset Pressure Switch
  • Available Voltages
    • Single Phase-115, 208, 230
    • Three Phase-208, 230, 460, 575*

Climate Control

Champion Pneumatic Climate Control
The Champion line of specially-designed climate control compressors represents years of intensive industrial research and testing. We’ve listened to the needs of the end user, and seen the short-comings of our competitors. The result is a line of machines suitable to critical industry demands for value and lasting performance. Features include low operating RPM for longer component life, lower operating temperatures, greater energy efficiency, inlet filter silencers and side-sealer piston rings (on selected models) for lower oil carry over.

  • 0.5-25 hp
  • 2.2 – 205 ACFM at 80 PSIG
  • Up to 175 PSIG maximum pressure on selected models
  • Tank or Base Mounted, Simplex & Duplex Models
  • Single & Two Stage
  • Air Cooled, Splash Lubricated
  • Heavy Duty Enclosed Belt Guard
  • Factory filled with AEON lubricant
  • Low oil carry over of 2 PPM
  • Low operating RPM
  • Lower operating temperatures
  • Greater energy efficiency
  • Inlet filter silencers
  • ASME coded air receiver
  • NEMA rated electric motors
  • Heavy duty enclosed belt guard
  • Manual receiver drain
  • 0-300 PSI air pressure gauge on receiver
  • Factory fill with ChampLub reciprocating compressor lubricant
  • 1-Year warranty

Value Plus

Champion Pneumatic Value Plus
The Value Plus compressor line was engineered for light industrial applications. Each compressor was designed with top quality bearings, cast iron cylinders, vibration free compressor pumps to insure longevity of the compressor package. The Value Plus is another quality product in the Champion line of air compressors.

  • 3 – 15 HP
  • 100 – 175 PSIG
  • 10.2 – 44.4 CFM
  • Single & Two-Stage Splash Lubricated
  • Electric Driven
  • Horizontal or Vertical Configuration
  • 2-Year compressor pump warranty
  • Standard Features
  • Magnetic Starters*
  • Automatic Start/Stop Operation
  • Heavy Duty Belt Guard
  • NEMA Rated Electric Motors
  • ASME Coded Air Receivers
  • Manual Tank Drain
  • 0-300 PSIG Air Pressure Gauge on Receiver
  • Preset Pressure Switch
  • Available Voltages: 208/230/460

Command Air

Champion Pneumatic Command Air
Champion’s full line of compact Command Air reciprocating air compressors are manufactured to the same quality standards as our larger, industrial models. These packages are sized for smaller air requirements such as small industrial plants, schools, small automotive centers, and do-it-yourselfers.

  • 0.5 – 3 HP
  • 90 PSIG
  • 1.8 – 10.2 CFM
  • Base or Tank Mounted, Vertical or Horizontal Configuration
  • Single Stage, Splash Lubricated
  • Automatic Start/Stop Operation
  • Loadless Starting via Pressure Switch
  • ODP NEMA 1760 RPM
  • 10 Micron Industrial Grade Intake Filter
  • Oil-Level Sight Gauge
  • Available Voltages
  • Single Phase – 115, 208, 230
  • Three Phase – 208, 230, 460

Air on Line

Champion Pneumatic Air on Line
The Champion industrial strength solid cast iron compressor pumps are designed for rugged applications. Low operating speeds reduce the wear and extend the life of the compressor package. Every Air-On-Line package is backed by over 1,000 authorized parts and service centers in the United States and a limited one-year warranty.

  • 1.5 – 8 HP
  • 100-175 PSIG
  • 4.3-15.7 CFM
  • Single & Two Stage
  • Splash Lubricated
  • Portable, Electric or Gas Driven
  • Hand-Held, Wheeled, Base Mount
  • Fully enclosed belt guard (where applicable)
  • Industrial grade semi pneumatic tires (where applicable)
  • Pressure gauges
  • Lift handles with rubber grips
  • Quick connect fitting
  • Belt tightener (where applicable)
  • Auto Start/Stop on electric models
  • Idle control for added safety (gas models)
  • Quality pilot valve (gas models)

A Series

Champion Pneumatic A Series
The A-series reputation has been built on reliability, quality, and accessibility to all components. Products include air-cooled bare compressors, boosters and vacuum pumps. A-Series compressors include counterbalanced crankshaft to ensure smooth operation, heavy duty cast iron construction, and deep-finned cylinders and heads, which quickly dissipate the heat of compression. Superior lubrication is accomplished through a gear driven positive displacement oil pump powered by the crankshaft. A-series bares and boosters are ideal for petroleum refineries, oil rigs, ore mines, plant air and vacuum, engine starting and well head servicing.

  • 15-40 HP (compressor or booster)
  • Up to 350 PSIG operating pressure
  • Single & Two Stage
  • 5-10 HP (vacuum)
  • Down to 28″ Hg vacuum
  • Pressure Lubricated
  • Heavy-duty cast iron construction
  • Factory filled with AEON lubricant
  • Compressor or Vacuum Pump with spin-on oil filter
  • Drive sheave with turbo fins
  • Suction unloading valves (SUV) or plain valves as indicated
  • Oil level dipstick
  • Factory fill of Champ Lub AC
  • Two-Stage include inter-cooler with pressure gauge and relief valve
  • *ANP Natural Gas Compressors have no exposed brass or copper components
  • *ANP Natural Gas Compressors include Viton o-rings and threaded crankcase vent connection
