Grippers
Reliable Vacuum Technology for Efficient Automated Material Handling
VacMotion’s line of grippers includes both Sprue Grippers and Foam Grippers, offering flexible solutions for a variety of automation tasks. Sprue Grippers are ideal for precise handling of molded parts, while Foam Grippers provide a soft, secure grip for delicate materials. These grippers integrate seamlessly with vacuum systems, ensuring reliable performance and adaptability in various industrial applications.
Explore VacMotion Vacuum Solutions for Reliable Industrial Performance
Foam Grippers
80mm x 60mm Foam Gripper (VFGS-80X60)
80mm x 60mm foam gripping system with built-in venturi.
- Size: 80mm x 60mm
- Supply Pressure PSI (bar): 58-116 (4-8)
- Air Consumption scfm (l/min): 2.11-2.97 (60-84)
- Max Flow scfm (l/min): 5.30 (150)
- Max Theoretical lifting force: 13
- Suction Holes (Qty): 15
- Weight lbs (Kg): .7350
- Max Theoretical lifting force = lbs at 24 in. Hg (80 kpa)
120mm x 60mm Foam Gripper (VFGS-120X60)
120mm x 60mm foam gripping system with built-in venturi.
- Size: 120mm x 60mm
- Supply Pressure PSI (bar): 58-116 (4-8)
- Air Consumption scfm (l/min): 2.47-3.53 (70-100)
- Max Flow scfm (l/min): 10.59 (300)
- Max Theoretical lifting force: 26.3
- Suction Holes (Qty): 21
- Weight lbs (Kg): 1.064
- Max Theoretical lifting force = lbs at 24 in. Hg (80 kpa)
160mm x 80mm Foam Gripper (VFGS-160X80)
160mm x 80mm foam gripping system with built-in venturi.
- Size: 160mm x 80mm
- Supply Pressure PSI (bar): 58-116 (4-8)
- Air Consumption scfm (l/min): 3.53-4.59 (100-130)
- Max Flow scfm (l/min): 13.77 (390)
- Max Theoretical lifting force: 44
- Suction Holes (Qty): 32
- Weight lbs (Kg): 1.894 (0.82)
- Max Theoretical lifting force = lbs at 24 in. Hg (80 kpa)
200mm x 115mm Foam Gripper (VFGS-200X115)
200mm x 115mm foam gripping system with built-in venturi.
- Size: 200mm x 115mm
- Supply Pressure PSI (bar): 58-116 (4-8)
- Air Consumption scfm (l/min): 14.13-16.24 (400-460)
- Max Flow scfm (l/min): 51.56 (1400)
- Max Theoretical lifting force: 70.3
- Suction Holes (Qty): 180
- Weight lbs (Kg): 3.20 (1.45)
- Max Theoretical lifting force = lbs at 24 in. Hg (80 kpa)
Sprue Grippers
Sprue Gripper Micro (MG.3010)
- Type: Sprue gripper
- Style: Micro
- Operating Pressure: 87 PSI
- Closing Force (N): 10
- Product weight(lbs): 0.018
Sprue Gripper Mini (MG.4010)
- Type: Sprue gripper
- Style: Mini
- Operating Pressure: 87 PSI
- Closing Force (N): 15
- Product weight(lbs): 0.03
Sprue Gripper Midi (MG.5010)
- Type: Sprue gripper
- Style: Midi
- Operating Pressure: 87 PSI
- Closing Force (N): 23
- Product weight(lbs): 0.082
Sprue Gripper Maxi (MG.6010)
- Type: Sprue gripper
- Style: Maxi
- Operating Pressure: 87 PSI
- Closing Force (N): 31
- Product weight(lbs): 0.082
Sprue Gripper (MG.6510)
- Type: Sprue gripper
- Two additional bore holes
- Operating Pressure: 87 PSI
- Closing Force (N): 31
- Max air pressure 6 bar
- Product weight(lbs): 0.082
- Length: 81mm
- Diameter 4,3mm
Sprue Gripper with Curved Jaws (GK.20.013)
- Type: Gripper
- Curved jaws
- Operating Pressure: 87 PSI
- Closing Force (N): 95
- Product weight(lbs): 0.263
- Clamping D= 20 mm
- Air inlet female thr. G 1/8
Sprue Gripper with Standard Jaws (GK.20.012)
- Type: Gripper
- Operating Pressure: 87 PSI
- Closing Force (N): 95
- Product weight(lbs): 0.266
- Clamping D= 20 mm
- Air inlet female thr. G 1/8
